星型卸料器+双螺旋给料机，某水泥有限公司SCR脱硝项目，闭风器(电动锁气器)安装环境：进口接拉链机卸料口，物料名称：水泥窑灰;堆积比重约0.7-1.0t/m³;进料粒度粉料(<0.3mm)物料温度：正常运行温度300℃;接口尺寸DN500;连续工作制。旋转给料器需带锁气功能，保证出口连接设备的气体不会泄露，漏风率为<1%。卸料器带配对法兰、密封垫和紧固件，垫片采用金属包覆石墨垫片。根据ANSI标准, 且不低于中国标准进行油漆。油漆表面质量要求：除锈等级：2.5;高温油漆(耐温250°)，漆膜厚度150um。星型卸料器下面接双螺旋给料机，水平输送，距离3~4米，配可是窗口，方便后期查看物料流动情况，国茂减速机，皖南电机。　　Star shaped unloader+double screw feeder, SCR denitration project of a cement limited company, installation environment of air shutter (electric air lock): imported zipper machine discharge port, material name: cement kiln ash; The bulk density is about 0.7-1.0t/m ³; Feed particle size powder (<0.3mm) Material temperature: Normal operating temperature of 300 ℃; Interface size DN500; Continuous work system. The rotary feeder needs to be equipped with a gas lock function to ensure that the gas connected to the outlet equipment will not leak, and the air leakage rate is less than 1%. The unloader is equipped with matching flanges, sealing gaskets, and fasteners, and the gaskets are made of metal coated graphite gaskets. Paint according to ANSI standards and not lower than Chinese standards. Surface quality requirements for paint: Rust removal grade: 2.5; High temperature paint (resistant to 250 ° C) with a film thickness of 150um. The star shaped unloader is connected to a double screw feeder for horizontal conveying, with a distance of 3-4 meters. It is equipped with a window for easy viewing of material flow in the later stage. Guomao reducer and Wannan motor.　　双螺旋输送机(又称双轴螺旋输送机)是一种利用‌两根平行且旋向相反‌的螺旋轴同步旋转，通过齿轮啮合驱动推动散装物料轴向移动的连续输送设备。同等规格下，输送量通常为单轴螺旋输送机的‌1.5至2倍‌。‌‌　　Double helix conveyor (also known as double helix conveyor) is a continuous conveying equipment that uses two parallel and opposite helical shafts to rotate synchronously, and drives the axial movement of bulk materials through gear meshing. Under the same specifications, the conveying capacity is usually 1.5 to 2 times that of a single axis screw conveyor. ‌‌　　双螺旋输送机性能：　　双轴反向啮合‌：两根平行螺旋轴(一左旋一右旋)通过齿轮同步啮合转动，物料在叶片间交替推挤，‌有效防止卡死和堵料‌。　　输送量大：双轴双重推力机制使输送能力达到同规格单轴机型的‌1.5 至 2 倍‌，适合中短距离大流量连续作业 。　　输送兼混合搅拌‌：输送过程中天然产生‌混合、搅拌、破碎‌效果，适用于需均化物料的场景。　　优异密封性‌：全封闭槽体(除进出料口外)，‌防尘防溢、防污染‌，适合环保要求高的工况。　　多点卸料：支持‌中间多点装料与卸料‌，槽盖可拆卸便于检修清理。　　物料适应性广‌：特别适合粉状、小颗粒及需搅拌的物料(如水泥、化肥、饲料);若为粘性/易缠绕物料，可定制或选双无轴‌变种以增强抗缠绕性。　　材质：陶瓷、碳化钨、尼龙、四氟、特氟龙、钛合金、铝合金、不锈钢、碳钢等。　　304(06Cr19Ni10)、316(06Cr17Ni12Mo2)、321(06Cr18Ni11Ti)、310S(06Cr25Ni20)、双相不锈钢2205(022Cr23Ni5Mo3N)、2507(022Cr25Ni7Mo4N)　　行业应用：食品、制药、化工、锂电新能源行业、水泥、冶金、矿山、环保、钢厂、电厂等。　　同得利公司在强化企业管理的基础上，依靠科技进步提高技术含量，先进的生产加工设备，优质的管理理念，高素质的员工团队，有效的质量保障体系和完善的售后服务，为制造高品质的产品提供可靠的保证，极大的满足了各行业的需求，深受广大客户的信赖。　　我公司始终坚持“质量第 一、用户至 上”的宗旨，服务于社会，诚信于业界，竭诚欢迎世界各地的业界好友光临指导，洽谈合作。　　Double helix conveyor performance:　　Dual axis reverse meshing: Two parallel spiral shafts (one left and one right) rotate synchronously through gears, and the material is alternately pushed between the blades, effectively preventing jamming and blockage.　　Large conveying capacity: The dual axis dual thrust mechanism enables the conveying capacity to reach 1.5 to 2 times that of single axis models of the same specifications, making it suitable for medium to short distance, high flow continuous operations.　　Conveying and mixing: During the conveying process, natural mixing, stirring, and crushing effects are generated, which is suitable for scenarios that require homogenization of materials.　　Excellent sealing performance: Fully enclosed tank body (except for inlet and outlet), dust-proof, spill proof, and pollution proof, suitable for working conditions with high environmental requirements.　　Multi point unloading: supports multi-point loading and unloading in the middle, and the groove cover is detachable for easy maintenance and cleaning.　　Wide material adaptability: particularly suitable for powders, small particles, and materials that require mixing (such as cement, fertilizers, and feed); If it is a viscous/easily entangled material, it can be customized or selected as a dual shaftless variant to enhance its resistance to entanglement.　　Materials: ceramics, tungsten carbide, nylon, PTFE, PTFE, titanium alloy, aluminum alloy, stainless steel, carbon steel, etc.　　304 (06Cr19Ni10), 316 (06Cr17Ni12Mo2), 321 (06Cr18Ni11Ti), 310S (06Cr25Ni20), duplex stainless steel 2205 (022Cr23Ni5Mo3N), 2507 (022Cr25Ni7Mo4N)　　Industry applications: food, pharmaceutical, chemical, lithium-ion new energy industry, cement, metallurgy, mining, environmental protection, steel mills, power plants, etc.　　On the basis of strengthening enterprise management, Tongdeli Company relies on technological progress to improve its technological content, advanced production and processing equipment, leading management concepts, high-quality employee team, effective quality assurance system and perfect after-sales service, providing reliable guarantees for manufacturing high-quality products, greatly meeting the needs of various industries, and deeply trusted by customers.　　Our company always adheres to the principle of "quality first, customer first", serves society, and is honest in the industry. We sincerely welcome industry friends from all over the world to visit and guide us, and negotiate cooperation.

　　不锈钢双轴破碎阀适用于输送量大、物料较硬、较大、较厚的物料破碎，因出料尺寸较大，适合初次/第 一道破碎工序，例如破碎大块的库底水泥块、铁矿石、煤块、粉煤灰、生活垃圾、大件垃圾、工业垃圾、锂电铁粉块料、彩钢瓦等。而单轴破碎阀则更适用二破，用于需要出料更小尺寸，破碎粉料块、塑料、垃圾等中硬、中薄物料。　　Stainless steel double axis crushing valve is suitable for crushing materials with large conveying capacity, hard, large, and thick materials. Due to the large discharge size, it is suitable for the initial/first crushing process, such as crushing large pieces of cement blocks, iron ore, coal blocks, fly ash, household waste, large garbage, industrial waste, color steel tiles, etc. Single axis crushing valves are more suitable for secondary crushing, used for crushing medium hard and thin materials such as powder blocks, plastics, and garbage that require smaller discharge sizes.　　不锈钢双轴破碎阀工作过程：　　1、进料‌：物料从顶部进料口进入阀腔，比如水泥库底受潮板结的料块、煤块、电石渣、沫煤、磷酸铁粉、电石渣烧生石灰、煤块、碳酸钙或废渣等。　　2、破碎‌：两根主轴由电机+减速机驱动，做同步反向旋转;轴上交错排列的刀片或破碎爪互相咬合，对物料形成剪切、撕扯和挤压，把大块料撕碎成小块。　　3、排料‌：破碎后的物料通过底部栅格板或筛网限位排出，颗粒大小由栅格间隙或刀型控制，通常可控制在1-5cm或小于10cm或6-10mm。‌‌　　Working process of stainless steel double axis crushing valve:　　1. Feed: Materials enter the valve chamber from the top feed inlet, such as wet and compacted blocks, coal blocks, carbide slag, foam coal, iron phosphate powder, carbide slag, quicklime, coal blocks, calcium carbonate or waste residue at the bottom of the cement silo.　　2. Crushing: Two main shafts are driven by motors and reducers to rotate synchronously in reverse; The blades or crushing claws arranged in a staggered manner on the shaft interlock with each other, forming shearing, tearing, and squeezing on the material, tearing large pieces of material into small pieces.　　3. Discharge: The crushed material is discharged through the bottom grid plate or sieve limit, and the particle size is controlled by the grid gap or blade shape, usually within 1-5cm or less than 10cm or 6-10mm　　双轴破碎阀的核心原理是：‌两根刀轴在电机驱动下相向旋转，通过刀片交错咬合产生的剪切、撕扯和挤压作用，把大块物料破碎成小颗粒‌。它本质上是一种带破碎功能的旋转卸料阀，主要用于防止物料结块堵塞下游设备。‌‌　　The core principle of a dual axis crushing valve is that two blade shafts rotate towards each other under the drive of a motor, and through the shearing, tearing, and squeezing effects generated by the interlocking of the blades, large pieces of material are crushed into small particles. It is essentially a rotary discharge valve with crushing function, mainly used to prevent material agglomeration from blocking downstream equipment. ‌‌　　不锈钢双轴破碎阀优势：　　出料粒度均匀‌：剪切效果好，破碎后物料尺寸更规整。‌‌　　破碎能力强‌：适合大块、硬质物料，如电石渣、水泥块、净化灰块状、沫煤、锂矿、金属、彩钢瓦、矿石等;且输送量大。　　运行更平稳‌：负荷分布在两个刀轴上，单轴磨损更小，设备寿命更长，噪音也相对较低。　　处理范围广‌：几乎能处理多种物料，包括炭黑结块、生活垃圾、建筑垃圾、电石渣烧生石灰、橡胶、编织袋等混合复杂物料，适应性优于单轴破碎阀。　　材质：SUS304、SUS316、钛材、喷涂碳化钨、陶瓷等。　　尺寸：DN100~~DN2000.方口100*100~~3000*4000.或非标定制。　　Advantages of stainless steel double axis crushing valve:　　Uniform particle size of the discharged material: good cutting effect, and the size of the crushed material is more regular. ‌‌　　Strong crushing ability: suitable for large and hard materials such as carbide slag, cement blocks, purified ash blocks, foam coal, lithium ore, metals, color steel tiles, ores, etc; And the conveying capacity is large.　　Run more smoothly: The load is distributed on two blade axes, resulting in less wear on each axis, longer equipment lifespan, and relatively lower noise.　　Wide processing range: It can handle almost various materials, including carbon black agglomerates, household waste, construction waste, carbide slag, quicklime, rubber, woven bags and other mixed complex materials, with better adaptability than single axis crushing valves.　　Materials: SUS304. SUS316. titanium, sprayed tungsten carbide, etc.　　Size: DN100~~DN2000. square mouth 100 * 100~~3000 * 4000. or non-standard customization.　　部分客户需求：　　双轴破碎机;物料：净化灰，物料堆积密度0.3~0.4t/m3.物料温度<300℃，物料粒度：90%≤10.但是易板结成块，破碎后粒径≤10mm。打散破碎机用于电石净化灰气力输送系统，净化灰由沉降罐自由落入下部输送仓泵内，由于净化灰的物料特殊性，运行过程净化灰含水量大、易板结，容易造成物料在沉降罐和除尘器灰斗内板结、架桥，造成下料困难。拟在沉降罐出口增加双轴破碎机，将堆积的块料通过破碎机破碎满足输送要求后落入仓泵内。区域要求：本区域为防爆区，电气仪表防爆等级为Extd A21 IP66 T80 ℃ IIIC,，电机防护等级IP66.电机厂家：佳木斯/南阳/锡安达/大中;减速机厂家：SEW/NORD/国茂。　　不锈钢电动双轴破碎阀，物料:电解锰片，堆积密度:2.1t/m³，原料粒度:厚度<3mm，大小为<100mm不规则片状，出料粒度:<20mm，规格:400mmx400mm，变频电动机，气体防爆、粉尘防爆，1.5KW，电压/频率:380V/50Hz。　　物料：化工结晶物料;进料粒度：进料边长 100~1500mm;额定处理量：5.0 t/h;材质：316L不锈钢整体锻造辊体(洁净化工物料通用);尺寸500×400mm;驱动形式：电机 + 减速机 + 齿轮同步传动，所有与物料接触零部件均为 316L 不锈钢，表面抛光处理，无毛刺划伤晶体。　　Partial customer requirements:　　Double axis crusher; Material: Purified ash, with a bulk density of 0.3~0.4t/m3. a material temperature of < 300 ℃, a material particle size of 90% ≤ 10. but prone to clumping and particle size ≤ 10mm after crushing. The dispersing crusher is used in the pneumatic conveying system of calcium carbide purified ash, and the purified ash freely falls into the lower conveying bin pump from the settling tank. Due to the special nature of the purified ash material, the water content of the purified ash is high and it is prone to clumping during operation, which can easily cause material clumping and bridging in the settling tank and dust collector ash hopper, resulting in difficulties in unloading. We plan to add a double axis crusher at the outlet of the settling tank to crush the accumulated block materials to meet the transportation requirements before they fall into the bin pump. Regional requirements: This area is an explosion-proof zone, with an explosion-proof rating of Extd A21 IP66 T80 ℃ IIIC for electrical instruments, and an IP66 protection rating for motors. Motor manufacturers: Jiamusi/Nanyang/Zinda/Dazhong; Gearbox manufacturer: SEW/NORD/Guomao.　　Stainless steel electric double axis crushing valve, material: electrolytic manganese sheet, bulk density: 2.1t/m ³, raw material particle size: thickness<3mm, irregular sheet size<100mm, discharge particle size:<20mm, specification: 400mmx400mm, variable frequency motor, gas explosion-proof, dust explosion-proof, 1.5KW, voltage/frequency: 380V/50Hz.　　Material: Chemical crystalline material; Feed particle size: feed side length 100~1500mm; rated processing capacity: 5.0 t/h; Material: 316L stainless steel integral forging roller body (universal for clean chemical materials); Size 500 × 400mm; Drive form: motor+reducer+gear synchronous transmission. All parts in contact with the material are made of 316L stainless steel, with a polished surface and no burrs or scratches on the crystal.　　我们的公司同得利生产电动破碎阀质量优良，性能稳定，使用寿命长。我们生产的双轴破碎阀和单轴破碎阀均具备优 秀的性能和质量保证，并能根据客户需求定制不同的规格和型号。我们不断推陈出新，不断创新产品，力争为客户提供更加优质的产品和服务，使客户的工作更加顺畅。如果您需要电动破碎阀或其它相关产品，欢迎咨询我公司，我们将为您提供蕞优质的服务。　　Our company Tongdeli produces electric crushing valves with excellent quality, stable performance, and long service life. Our dual axis crushing valves and single axis crushing valves have excellent performance and quality assurance, and can be customized with different specifications and models according to customer needs. We constantly innovate and innovate our products, striving to provide customers with better quality products and services, making their work smoother. If you need electric crushing valves or other related products, please feel free to consult our company, and we will provide you with the best quality service.　　破碎旋转阀、打散卸料器、不锈钢破碎阀、不锈钢双轴破碎阀、不锈钢双轴旋转破碎阀、304不锈钢管道破碎机、316不锈钢破碎卸料阀、310不锈钢电动破碎阀、不锈钢破碎打散阀、304不锈钢双轴打散阀

　　尼龙星型卸料阀适用于锂电正极材料输送，高镍三元材料，磷酸铁锂。阀体、端盖外表面采用304.物料接触8-10mm氧化铝陶瓷工艺等。都可以满足工况耐磨，耐温尤为突出。　　耐磨性强：尼龙卸料阀采用高性能改性尼龙材料制作，具有极高的硬度和耐磨性，能够在高速物料流动和摩擦的环境下长时间使用。　　耐高温性能好：尼龙卸料阀可以在高温环境下正常工作，能够承受高温物料的冲击和摩擦，确保设备的稳定性和安全性。　　此产品由本公司自主研制，适用于不可接触金属物料的卸料。箱体、叶轮以及端盖，都采用整块尼龙铣削加工，结构牢靠，运行无噪音，相较于陶瓷阀，可以节省成本，是锂电行业新宠。　　Nylon star discharge valve is suitable for conveying lithium battery positive electrode materials, high nickel ternary materials, and lithium iron phosphate. The outer surface of the valve body and end cover adopts 304 material contact 8-10mm alumina ceramic technology, etc. Both can meet the wear resistance requirements of working conditions, with outstanding temperature resistance.　　Strong wear resistance: The nylon discharge valve is made of high-performance modified nylon material, which has extremely high hardness and wear resistance, and can be used for a long time in environments with high-speed material flow and friction.　　Good high-temperature resistance: The nylon discharge valve can work normally in high-temperature environments, withstand the impact and friction of high-temperature materials, and ensure the stability and safety of the equipment.　　This product is independently developed by our company and is suitable for unloading non-contact metal materials. The casing, impeller, and end cover are all processed using a single piece of nylon milling, with a reliable structure and noiseless operation. Compared to ceramic valves, they can save costs and are a new favorite in the lithium battery industry.

　　高温物料破碎阀，物料温度可达1100℃，如水泥厂悬浮窑、锅炉排渣、新材料煅烧破碎高温物料等工况，轴水冷工艺，降低物料温度。　　电动旋转破碎阀的核心原理是：‌用旋转的带齿转子或破碎爪，把卸料过程中出现的结块物料剪切、打散成能顺利通过的小块，再配合阀体的卸料动作完成输送‌。它不只是控制通断，重 点是“边卸料边破碎”。‌‌　　破碎阀把“定量卸料”和“破碎防堵”合在了一起，常用在食品粉料块、化工粉体、锂电块料原料、库底水泥、粉煤灰、煤粉等容易吸潮结块的物料仓底或气力输送系统里。‌‌　　High temperature material crushing valve, with material temperature up to 1100 ℃, suitable for working conditions such as cement plant suspension kiln, boiler slag discharge, new material calcination and crushing of high-temperature materials, and shaft water cooling process to reduce material temperature.　　The core principle of the electric rotary crushing valve is to use a rotating toothed rotor or crushing claw to cut and break up the clumped materials that appear during the unloading process into small pieces that can pass smoothly, and then cooperate with the unloading action of the valve body to complete the conveying. It's not just about controlling on/off, the focus is on "unloading while crushing". ‌‌　　The crushing valve combines "quantitative discharge" and "crushing and anti blocking", and is commonly used in the bottom of material warehouses or pneumatic conveying systems that are prone to moisture absorption and agglomeration, such as food powder blocks, chemical powders, lithium battery block raw materials, warehouse bottom cement, fly ash, coal powder, etc. ‌‌　　高温物料破碎阀/耐高温水冷式破碎阀：　　本产品精选耐高温轴承，箱体叶轮轴承座采用循环水冷却，能承受1100度高温。通过循环水带走阀体吸收的热量，使内部轴承、密封件等关键部件维持在安全工作温度，防止因高温导致卡死或泄漏。‌‌本系列产品也可根据用户特殊要求定制技术参数。　　High temperature material crushing valve/high temperature resistant water-cooled crushing valve:　　This product selects high-temperature resistant bearings, and the housing impeller bearing seat adopts circulating water cooling, which can withstand a high temperature of 1100 degrees. By circulating water to remove the heat absorbed by the valve body, key components such as internal bearings and seals are maintained at safe operating temperatures to prevent jamming or leakage caused by high temperatures. This series of products can also be customized with technical parameters according to users' special requirements.　　高温物料破碎阀主要特点：　　1、防堵破碎‌：能处理磷酸铁粉、沫煤、锂矿、结块颗粒、电石渣、碳酸钙、硬脂酸盐结块、水泥块等块状物料，避免堵塞卸料口。　　2、连续卸料‌：均匀连续输送物料，结构紧凑，运转平稳、噪音低。　　3、‌锁气密封‌：有效阻止气流逆向流动，保证系统气压稳定，适合正压或负压状态下的卸料。　　4、材质多样‌：可根据工况选择不锈钢等材质、内衬陶瓷、喷涂碳化钨、耐磨合金、高锰钢材质，适应腐蚀性、高温或高洁净要求的环境。　　5、安全保护(选配)‌：部分产品带电机转速检测装置，卡料时会报警并自动反转，把无法破碎的物料推开后再正转;正反转都被卡住时自动停机。电机、减速机标配品牌：皖南、卧龙、国茂、西门子、ABB、SEW、Flender、NORD、住友，或客户指定品牌。　　Main features of high-temperature material crushing valve:　　1. Anti blocking and crushing: It can handle block materials such as phosphate iron powder, foam coal, lithium ore, agglomerated particles, carbide slag, calcium carbonate, stearate agglomerates, cement blocks, etc., to avoid blocking the discharge port.　　2. Continuous unloading: Uniform and continuous conveying of materials, compact structure, smooth operation, and low noise.　　3. Lock gas seal: effectively prevents reverse airflow, ensures stable system pressure, and is suitable for unloading under positive or negative pressure conditions.　　4. Diverse materials: Stainless steel and other materials, ceramic lining, sprayed tungsten carbide, wear-resistant alloy, high manganese steel materials can be selected according to the working conditions to adapt to environments with corrosive, high temperature, or high cleanliness requirements.　　5. Safety protection (optional): Some products are equipped with a motor speed detection device, which will alarm and automatically reverse when stuck, pushing the unbreakable material away and then rotating forward again; Automatically stop when both forward and reverse directions are stuck. Standard brands for motors and reducers: Wannan, Wolong, Guomao, Siemens ABB、SEW、Flender、NORD、 Sumitomo, or customer designated brand.　　部分客户需求：　　高温水冷卸料破碎阀，规格：圆形DN400.耐温：500-1000℃，物料堆积密度：0.5-0.8g/cm³，物料处理量：10t/h。适用介质：煤矸石、方解石等高温粉料块料，阀内压力：±10000Pa，形态方式：旋转式。类型通道：直通式，流动方向：单向，驱动方式：电动，连接形式：法兰式连接，进出口尺寸：DN400.阀体与电机减速机分体式。阀体及附加设备需刷防护面漆。阀体要求机械密封及阀轴处，完全气密封，避免外部空气因负压吸入阀体内，建议采用惰性气体气封或采用其他方式阻绝外部空气进入，同时考虑阀体正压出现跑料现象。　　Partial customer requirements:　　High temperature water-cooled discharge crushing valve, specification: circular DN400. temperature resistance: 500-1000 ℃, material bulk density: 0.5-0.8g/cm ³, material processing capacity: 10t/h. Applicable medium: high-temperature powder blocks such as coal gangue and calcite, valve pressure: ± 10000Pa, form: rotary type. Type channel: straight through, flow direction: one-way, drive mode: electric, connection form: flange connection, inlet and outlet size: DN400. valve body and motor reducer are separated. The valve body and additional equipment need to be coated with protective paint. The valve body requires mechanical sealing and complete gas sealing at the valve shaft to prevent external air from being sucked into the valve body due to negative pressure. It is recommended to use inert gas gas sealing or other methods to block external air from entering, while considering the phenomenon of material leakage caused by positive pressure on the valve body.　　水冷耐高温旋转破碎阀，物料接触材质：310S，进料温度1000度(max)物料密度约700kg/m³，物料额定输送量2600kg/h(输送量变频可调)阀体表面喷涂：有机硅高温铝粉漆，油漆干膜厚度60um，轴密封形式：纯石墨盘根密封，减速机：SEW，电机卧龙。　　耐高温卸料破碎阀  耐高温旋转破碎阀  耐高温破碎打散阀 耐高温破碎阀 耐高温电动破碎阀 水冷式破碎阀  水冷式电动破碎阀 水冷式破碎卸料阀 水冷式破碎旋转阀　　我们的公司同得利生产电动破碎阀质量优良，性能稳定，使用寿命长。我们生产的高温破碎阀、双轴破碎阀和单轴电动破碎阀均具备优 秀的性能和质量保证，并能根据客户需求定制不同的规格和型号。我们不断推陈出新，不断创新产品，力争为客户提供更加优质的产品和服务，使客户的工作更加顺畅。如果您需要电动破碎阀或其它相关产品，欢迎咨询我公司，我们将为您提供蕞优质的服务。     《扫二维码-添加 陈经理 微信-咨询水冷式耐高温破碎卸料阀》　　Water cooled high-temperature resistant rotary crushing valve, material contact material: 310S, feed temperature of 1000 degrees (max), material density of about 700kg/m ³, rated material conveying capacity of 2600kg/h (variable frequency adjustable conveying capacity), valve body surface spraying: organic silicon high-temperature aluminum powder paint, paint dry film thickness of 60um, shaft sealing form: pure graphite disc root seal, reducer: SEW, motor Wolong.　　Our company Tongdeli produces electric crushing valves with excellent quality, stable performance, and long service life. Our high-temperature crushing valves, double axis crushing valves, and single axis electric crushing valves all have excellent performance and quality assurance, and can be customized with different specifications and models according to customer needs. We constantly innovate and innovate our products, striving to provide customers with better quality products and services, making their work smoother. If you need electric crushing valves or other related products, please feel free to consult our company, and we will provide you with the best quality service.

　　脱硫脱硝项目上面用刚性叶轮给料机，电石净化过滤器内高温净化灰，DN400.2.2KW，处理能力≥2t/h，0.1MPa,≥230℃;DN600.4KW，处理能力≥6t/h，0.1MPa,≥500℃。刚性叶轮给料机(又称刚性分格轮卸料器、回转给料机等)是一种用于输送高温物料、坚硬物料、块状物料、干燥粉状物料的定量给料与锁气设备，具有非常好的承重性。　　脱硫：脱去烟气中的二氧化硫，防止形成酸雨。　　脱硝：脱去烟气中的氮氧化物，减少大气污染。　　主要应用：火电厂、钢铁厂、水泥厂等燃煤锅炉烟气治理。　　常见技术：石灰石 - 石膏法(脱硫)、SCR/SNCR 催化还原法(脱硝)。‌‌　　刚性叶轮给料机作用：　　实现均匀、连续的定量给料：它利用旋转的叶轮，将上方料仓中的粉状或小颗粒物料，均匀、连续地喂送到下一道工序设备中。通过选用调速电机，还可以按需调节给料量。　　提供可靠的锁气与密封：在除尘或气力输送系统中隔断上下部气压差，‌阻止气流串通‌，维持系统负压/正压稳定。　　‌卸灰排料‌：作为除尘器灰斗底部装置，高 效排出收集的粉尘或颗粒，‌抑制二次扬尘‌与泄漏。‌‌　　刚性叶轮给料机主要用于钢厂、电厂、水泥、矿山等行业。　　材质：304~316.Q235.Q355.耐磨400.耐磨500.高锰钢(ZG120Mn18Cr2/Mn13)，耐磨合金，陶瓷等。　　部分客户需求：　　刚性叶轮给料机输送能力：8t/h-10t/h;工作温度：50℃-300℃;工作介质：固体粉末状颗粒物料，流动性差，平均粒度：45-150μm;堆积密度：2500-3000kg/m³，物料中夹杂有HF、H2O(气体);电源电压：380V。　　刚性叶轮给料机阀体材质：HT350.端板材质：Q235B;转轴材质：45#;叶片材质：Q235B;密封垫圈采用聚四氟乙烯材质;电机：功率3Kw，0-1400r/min，可调频，防护等级：IP65.绝缘等级：F级。　　输送物料水泥，稳流仓装置，刚性叶轮给料机，尺寸DN500.输送计量范围80t/h，材质Q235.　　物料：煤粉，型号:WLF-500.材质:Q355B，DN600.齿轮减速电动机(变频电机，3kW)，聚四氟密封条。　　物料：电石净化过滤器内高温净化灰，DN400.2.2KW，处理能力≥2t/h，0.1MPa,≥230℃;DN600.4KW，处理能力≥3t/h，0.1MPa,≥500℃。　　常州同得利/江苏同得利专 业生产(B)GFY、YJD系列关风机(关风器)、星型卸料器、DS系列电动锁气器、DN型旋转阀，快开清洗阀、防卡旋转阀、偏置防卡、风送直通式旋转阀、高温高压旋转阀、高温水冷式、刮板式自清洁、钛合金陶瓷碳化钨四氟特氟龙尼龙聚氨酯、破拱机、料仓刮料破拱器、打散破碎阀、螺旋输送机等产品。广泛应用于锂电池、食品、石油化工、制药、淀粉、油脂、化工干燥、粮食、饲料、塑料、除尘、冶金、环保、电子、煤炭、建筑、电力机械等行业设备上。用于固体粒料、粉料、超微粉体在气力输送及管网正负压状态下的卸料。         《扫二维码-添加 陈经理 微信-咨询刚性叶轮给料机》　　On the desulfurization and denitrification project, a rigid impeller feeder is used, and high-temperature purified ash is purified in the carbide purification filter, DN400.2.2KW， Processing capacity ≥ 2t/h, 0.1MPa, ≥ 230 ℃; DN600.4KW， Processing capacity ≥ 6t/h, 0.1MPa, ≥ 500 ℃. A rigid impeller feeder (also known as a rigid dividing wheel unloader, rotary feeder, etc.) is a quantitative feeding and air locking device used for conveying high-temperature materials, hard materials, block materials, and dry powder materials, with excellent load-bearing capacity.　　Desulfurization: Removing sulfur dioxide from flue gas to prevent the formation of acid rain.　　Denitrification: Removing nitrogen oxides from flue gas and reducing air pollution.　　Main applications: flue gas treatment of coal-fired boilers in thermal power plants, steel plants, cement plants, etc.　　Common techniques: limestone gypsum method (desulfurization), SCR/SNCR catalytic reduction method (denitrification). ‌‌　　Function of rigid impeller feeder:　　Realize uniform and continuous quantitative feeding: It uses a rotating impeller to uniformly and continuously feed powdered or small particle materials from the upper silo to the next process equipment. By selecting a speed regulating motor, the feeding amount can also be adjusted as needed.　　Provide reliable air locking and sealing: isolate the pressure difference between the upper and lower parts in dust removal or pneumatic conveying systems, prevent air flow collusion, and maintain stable negative/positive pressure in the system.　　Unloading and discharging: As a bottom device of the dust collector ash hopper, it efficiently discharges collected dust or particles, suppressing secondary dust and leakage. ‌‌　　Rigid impeller feeders are mainly used in industries such as steel mills, power plants, cement, and mining.　　Material: 304~316. Q235.Q355. Wear resistant 400. wear resistant 500. high manganese steel (ZG120Mn18Cr2/Mn13), wear-resistant alloy, ceramics, etc.　　Partial customer requirements:　　Rigid impeller feeder conveying capacity: 8t/h-10t/h; Working temperature: 50 ℃ -300 ℃; Working medium: Solid powder like granular material with poor flowability, average particle size: 45-150 μ m; Bulk density: 2500-3000kg/m ³, with HF and H2O (gases) mixed in the material; Power supply voltage: 380V.　　Rigid impeller feeder valve body material: HT350. end plate material: Q235B; Spindle material: 45 #; Blade material: Q235B; The sealing gasket is made of polytetrafluoroethylene material; Motor: power 3Kw, 0-1400r/min, adjustable frequency, protection level: IP65. insulation level: F.　　Conveying material cement, stable flow bin device, rigid impeller feeder, size DN500. conveying measuring range 80t/h, material Q235.　　Material: coal powder, model: WLF-500. material: Q355B, DN600. gear reduction motor (variable frequency motor, 3kW), PTFE sealing strip.　　Material: High temperature purified ash inside the carbide purification filter, DN400.2.2KW， Processing capacity ≥ 2t/h, 0.1MPa, ≥ 230 ℃; DN600.4KW， Processing capacity ≥ 3t/h, 0.1MPa, ≥ 500 ℃.　　Changzhou Tongdeli/Jiangsu Tongdeli specializes in the production of (B) GFY and YJD series air shut-off fans (air shut-off devices), star shaped unloaders, DS series electric air locks, DN type rotary valves, quick opening cleaning valves, anti jamming rotary valves, offset anti jamming, air delivery straight through rotary valves, high-temperature and high-pressure rotary valves, high-temperature water-cooled, scraper self-cleaning, titanium alloy ceramic tungsten carbide PTFE nylon polyurethane, arch breakers, silo scraper crushers, dispersing and crushing valves, screw conveyors and other products. Widely used in equipment for industries such as lithium batteries, food, petrochemicals, pharmaceuticals, starch, oils, chemical drying, grain, feed, plastics, dust removal, metallurgy, environmental protection, electronics, coal, construction, and power machinery. Used for unloading solid granules, powders, and ultrafine powders under pneumatic conveying and positive and negative pressure in pipeline networks.

　　破碎水泥块料，出料细度≤30mm，温度≤120℃，双轴机构，轴承外置，密封机构和轴承底座各自独立，均可单独拆卸;阀体上部设计检修口。电机功率11KW  YE4.皖南电机，电机电压380V，国茂GFAF99减速机，输出转速42rpm。壳体：材质16Mn，壳体四面侧板、进出料口法兰、筋板厚度均大于等于12mm，轴承底座安装位置板厚≥35mm。破碎栅网：栅网板厚12mm，材质handox400.设计结构保证不堵料，耐热处理，增加高温时结构稳定性。轴承底座：铸钢材质，整体铸造，法兰厚度≥30mm，高温隔离涂层。刀片：材质HARDOX 400.厚度12mm，刀片尖 端宽度≥70mm。轴：基础材质40Cr，直径107mm，调质处理，密封机构配合位置镀铬处理，镀层厚度≥0.3mm，磨削抛光至镜面。轴中心打40mm贯穿通用，用以风冷。输出轴密封结构：密封方式采用迷宫密封+机械密封，密封组件可以单独注油润滑。密封底座内部设计径向双层散热腔体，可气冷散热。密封底座为浮动底座结构，用以使用轴在运行中的摆动。齿轮材质及厚度40Cr/95mm。　　水泥在库内受潮或存放时间过长容易结块，破碎阀能将这些大块料打散，避免卡住下方的卸料阀门或输送通道 。它并不是用来粉磨水泥粉的独立破碎机，而是在线破碎打散块料装置。目前水泥厂常用电动破碎阀，可实现远程控制。常见有‌单轴‌和‌双轴‌结构，双轴结构在处理较硬结块时能力更强，输送量更大，但需根据实际工况选择。常见型号包括PSF系列破碎阀(如 PSF300、PSF500、PSF600、PSF1000)和 PKD系列(如PKD400、 PKD500、PKD700、PKD800)，数字通常代表通道尺寸(如 400×400mm、800x800mm)。关键破碎部件常采用‌耐磨锰钢‌或合金钢，以应对高磨损工况。‌‌‌　　双轴破碎阀工作原理：　　物料从进料口进入破碎腔后，由电机或液压马达通过减速机驱动两根刀辊反向旋转，刀片钩住物料进行强力剪切、撕扯和挤压，把大块物料破碎成小块，再通过刀辊间隙或底部筛网排出。‌‌　　双轴系统‌：主动轴与从动轴通过齿轮箱联动，实现同步反向旋转，两轴刀片错位排列。　　定刀配合‌：箱体内壁的梳型齿板(定刀)与旋转刀片之间留有可调剪切间隙(常见0.5-5mm)，形成动刀+定刀的双重剪切结构。　　驱动方式‌：多数采用双电机独立驱动或单电机+齿轮箱联动，破碎时转速较低但扭矩大，剪切力更强。‌‌　　破碎阀刀片材质选择包括不锈钢系列、高碳钢、合金钢、高速钢和硬质合金。这些材质各有其独特的优点，适用于不同的工况。　　水泥破碎阀 块料破碎阀 电动块料破碎器 电动破碎阀  粉煤灰破碎阀  电石渣破碎阀  斜槽水泥块料破碎阀 水泥结块打散卸料阀　　部分客户需求：　　500*500双轴电动破碎阀;规格(内径)500X500.物料：水泥等;通过量(出料能力)≥400t/h;蕞大颗粒15-20mm;物料温度<120℃;出料粒径≤20mm;壳体材质Q235.厚度10mm;皖南电机,YE4;减速机输出转速48;国茂减速机。　　物料：水泥粉末，散装，部分结块，固体颗粒密度3.1t/m³，体积密度1.35/m³，含水率不超过3%，需求：双轴水泥破碎机和回转给料机的替代产品，产能为6立方米/小时。该双轴破碎机和回转给料机安装在水泥仓下方，用于破碎蕞大粒径达35毫米的水泥结块。破碎机进料口需大于100mm。　　我公司专 业生产(B)GFY、YJD系列关风机(关风器)、星型卸料器、DS系列电动锁气器、YJD型旋转阀，快开清洗阀、防卡旋转阀、偏置防卡、风送直通式旋转阀、高温高压旋转阀、高温水冷式、刮板式自清洁、钛合金陶瓷碳化钨四氟特氟龙尼龙聚氨酯、破拱机、料仓刮料破拱器、打散破碎阀、螺旋输送机等产品。广泛应用于锂电池、食品、石油化工、制药、淀粉、油脂、化工干燥、粮食、饲料、塑料、除尘、冶金、环保、电子、煤炭、建筑、电力机械等行业设备上。用于固体粒料、粉料、超微粉体在气力输送及管网正负压状态下的卸料。　　Crushed cement block material, with a discharge fineness of ≤ 30mm and a temperature of ≤ 120 ℃, equipped with a dual axis mechanism, external bearings, independent sealing mechanism, and bearing base that can be disassembled separately; The upper part of the valve body is designed with a maintenance port. Motor power 11KW YE4. Wannan Motor, motor voltage 380V, Guomao GFAF99 reducer, output speed 42rpm. Shell: Made of 16Mn material, the thickness of the four side plates, inlet and outlet flanges, and rib plates of the shell is greater than or equal to 12mm, and the thickness of the bearing base installation position plate is greater than or equal to 35mm. Crushing grid: The grid plate thickness is 12mm, made of Handox400 material, designed with a structure to ensure no material blockage, heat-resistant treatment, and increased structural stability at high temperatures. Bearing base: made of cast steel material, integral casting, flange thickness ≥ 30mm, high temperature isolation coating. Blade: Material HARDOX 400. thickness 12mm, blade tip width ≥ 70mm. Shaft: Base material 40Cr, diameter 107mm, quenched and tempered, sealing mechanism matching position chrome plated, coating thickness ≥ 0.3mm, ground and polished to mirror finish. 40mm through the center of the shaft for universal use, used for air cooling. Output shaft sealing structure: The sealing method adopts labyrinth seal+mechanical seal, and the sealing components can be separately lubricated with oil. The sealed base is designed with a radial double-layer heat dissipation chamber inside, which can be air-cooled for heat dissipation. The sealing base is a floating base structure used for the swing of the shaft during operation. Gear material and thickness: 40Cr/95mm.　　Cement that is damp or stored for too long in the warehouse is prone to clumping. The crushing valve can break up these large pieces of material and avoid getting stuck in the discharge valve or conveying channel below. It is not an independent crusher used for grinding cement powder, but an online crushing and dispersing block material device. At present, electric crushing valves are commonly used in cement plants, which can achieve remote control. There are commonly single axis and double axis structures. The double axis structure has stronger ability to handle harder lumps and has a larger conveying capacity, but it needs to be selected according to the actual working conditions. Common models include PSF series crushing valves (such as PSF300. PSF500. PSF600. PSF1000) and PKD series (such as PKD400. PKD500. PKD700. PKD800), with numbers typically representing channel sizes (such as 400 × 400mm, 800x800mm). Key crushing components are often made of wear-resistant manganese steel or alloy steel to cope with high wear conditions. ‌‌‌　　Working principle of dual axis crushing valve:　　After the material enters the crushing chamber from the feeding port, it is driven by a motor or hydraulic motor through a reducer to rotate two knife rollers in the opposite direction. The blades hook onto the material for strong shearing, tearing, and squeezing, crushing large pieces of material into small pieces, and then discharging them through the gap between the knife rollers or the bottom screen. ‌‌　　Dual axis system: The driving shaft and the driven shaft are linked through a gearbox to achieve synchronous reverse rotation, with the blades of the two shafts arranged in a staggered manner.　　Fixed blade coordination: There is an adjustable cutting gap (usually 0.5-5mm) between the comb shaped toothed plate (fixed blade) on the inner wall of the box and the rotating blade, forming a dual cutting structure of moving blade and fixed blade.　　Drive mode: Most of them use dual motor independent drive or single motor+gearbox linkage. When crushing, the speed is low but the torque is high, and the shear force is stronger. ‌‌　　The material selection for the crushing valve blade includes stainless steel series, high carbon steel, alloy steel, high-speed steel, and hard alloy. These materials each have their unique advantages and are suitable for different working conditions.　　Cement crushing valve, block material crushing valve, electric block material crusher, electric crushing valve, fly ash crushing valve, electric stone slag crushing valve, inclined groove cement block material crushing valve, cement agglomeration dispersing discharge valve　　Partial customer requirements:　　500 * 500 dual axis electric crushing valve; Specification (inner diameter) 500X500. material: cement, etc; Throughput (discharge capacity) ≥ 400t/h; Maximum particle size 15-20mm; material temperature < 120 ℃; Discharge particle size ≤ 20mm; shell material Q235. thickness 10mm; Wannan Motor, YE4; The output speed of the reducer is 48; Guomao reducer.　　Material: Cement powder, loose, partially agglomerated, solid particle density of 3.1t/m ³, bulk density of 1.35/m ³, moisture content not exceeding 3%, demand: alternative products for dual axis cement crushers and rotary feeders, with a production capacity of 6 cubic meters per hour. The dual axis crusher and rotary feeder are installed below the cement silo for crushing cement lumps with a maximum particle size of 35 millimeters. The feed inlet of the crusher needs to be larger than 100mm.　　Our company specializes in the production of (B) GFY, YJD series air shut-off fans (air shut-off devices), star shaped unloaders, DS series electric air locks, YJD type rotary valves, quick opening cleaning valves, anti jamming rotary valves, offset anti jamming, air delivery straight through rotary valves, high temperature and high pressure rotary valves, high temperature water-cooled, scraper self-cleaning, titanium alloy ceramic tungsten carbide PTFE PTFE nylon polyurethane, arch breaking machines, silo scraper crushers, fragmentation valves, screw conveyors and other products. Widely used in equipment for industries such as lithium batteries, food, petrochemicals, pharmaceuticals, starch, oils, chemical drying, grain, feed, plastics, dust removal, metallurgy, environmental protection, electronics, coal, construction, and power machinery. Used for unloading solid granules, powders, and ultrafine powders under pneumatic conveying and positive and negative pressure in pipeline networks.

　　化工物料：三氯化锂，需要破碎打散阀，高密封不能进空气，耐腐蚀，破碎至小于30mm，破碎后卸料量10t/h，材质不锈钢，以前用过德国科倍隆的，现在需要换成国产好点的品牌。高纯盐酸(HCl)次氯酸钠(NaClO)合成盐酸(HCl)食品级盐酸，液氯(Cl₂)高品质氢氧化钾。　　什么叫破碎阀打散机?作用是什么?　　破碎阀打散机具备星型卸料阀定量卸料和锁气密封功能+打散破碎大块料功能。物料进入下游设备前，把因受潮、挤压等原因形成的‌结块或大块物料打散、破碎‌，防止堵料，保证卸料和输送通畅。‌‌破碎阀通常‌水平或垂直安装在料仓、库底的卸料出口处‌，也就是流量调节阀或气动切断阀的前部。圆形法兰和方形法兰。　　Chemical material: Lithium trichloride, requires crushing and dispersing valve, high sealing cannot allow air to enter, corrosion-resistant, crushed to less than 30mm, unloading capacity after crushing is 10t/h, made of stainless steel, previously used by German Kobelon, now needs to be replaced with a better domestic brand. High purity hydrochloric acid (HCl) and sodium hypochlorite (NaClO) are used to synthesize food grade hydrochloric acid (HCl) and high-quality potassium hydroxide for liquid chlorine (Cl ₂).　　What is a crushing valve disperser? What is its function?　　The crushing valve disperser has the functions of star shaped discharge valve quantitative discharge and air lock sealing, as well as the function of dispersing and crushing large blocks. Before entering downstream equipment, the clumps or large pieces of material formed due to moisture, compression, etc. should be dispersed and broken to prevent blockage and ensure smooth unloading and transportation. The crushing valve is usually installed horizontally or vertically at the discharge outlet of the silo or at the bottom of the silo, that is, at the front of the flow regulating valve or pneumatic cut-off valve. Circular flange and square flange.　　‌防堵防拱‌：把料仓里因受潮、挤压形成的料拱和结块打碎，让物料能顺畅流出来，避免卸料口堵塞。　　均匀给料‌：打散后的物料松散均匀，能给下游的给料螺旋、称重计量设备等持续稳定供料，避免忽多忽少影响烘干或计量效果。　　锁气密封‌：如气力输送：正压/负压输送系统，可带锁气功能，卸料时能隔绝内外气流，维持除尘系统负压稳定，防止漏风影响效率。‌‌　　Anti blocking and anti arching: smash the material arches and lumps formed by moisture and compression in the material warehouse, so that the materials can flow smoothly and avoid blockage of the discharge port.　　Uniform feeding: After being dispersed, the material is loose and uniform, which can provide continuous and stable feeding to downstream feeding screws, weighing and measuring equipment, etc., avoiding fluctuations that may affect the drying or measuring effect.　　Gas locking seal: such as pneumatic conveying: positive/negative pressure conveying system, can be equipped with gas locking function, can isolate internal and external airflow during unloading, maintain stable negative pressure of the dust removal system, and prevent air leakage from affecting efficiency.　　‌电动破碎阀‌：电机经减速机构驱动破碎主轴，适合处理粉料结块，常用于水泥库底、粉煤灰等卸料系统。　　旋转破碎阀‌：内部旋转叶轮将物料分割到叶片腔室中，边破碎边均匀输送，适合锂电、化工、食品等行业。　　尺寸：圆口DN100~~DN2000.方口100*100~~3000*4000.或非标定制。　　材质：SUS304、SUS316、钛材。　　破碎出料粒度：6mm~10mm，或1cm~3cm，或<6mm定制，均可按需定制。　　Electric crushing valve: The motor drives the crushing spindle through a reduction mechanism, which is suitable for processing powder agglomerates and is commonly used in cement silo bottoms, fly ash and other unloading systems.　　Rotary crushing valve: The internal rotating impeller divides the material into blade chambers and evenly transports it while crushing, suitable for industries such as lithium batteries, chemicals, and food.　　Dimensions: Round mouth DN100~~DN2000. square mouth 100 * 100~~3000 * 4000. or non-standard customization.　　Material: SUS304. SUS316. titanium.　　Crushed material particle size: 6mm~10mm, or 1cm~3cm, or<6mm can be customized according to needs.　　不锈钢打散卸料器，不锈钢破碎阀，不锈钢电动破碎阀，不锈钢破碎卸料器，旋转破碎阀，旋转打散阀，卸料器破碎机，方口破碎阀，方形破碎阀，方形打散阀，管道打散破碎阀，电动打散机破碎阀，不锈钢304破碎阀，不锈钢316L破碎阀，锂电专用破碎阀，锂电池行业专用打散破碎阀，化工破碎卸料器，化工专用破碎打散阀　　Stainless steel breaking unloader, stainless steel crushing valve, stainless steel electric breaking valve, stainless steel breaking unloader, rotary breaking valve, rotary breaking valve, unloader crusher, square mouth breaking valve, square breaking valve, square breaking valve, pipeline breaking valve, electric breaking valve, stainless steel 304 breaking valve, stainless steel 316L breaking valve, lithium battery professional breaking valve, lithium battery industry specific breaking valve, chemical breaking unloader, chemical specific breaking valve　　部分客户需求：　　物料：阳极碳块，原料小颗粒状，经过某工艺结块7~10cm，需要不锈钢破碎阀打散成小块料，下料口尺寸500*500.破碎到2~3cm左右，电机要求一级能效防爆的皖南，减速机国茂，材质不锈钢SUS316.　　破碎粒径:碎前2-5cm，碎后8mm;设计产能:4.5t/h;驱动方式:直连;表面要求:内表面抛光Ra0.4.外表面Sa2;物料：锂电池碳酸锂:4.5t/h，堆密度380kg/cm2.D90=13um。形式:对齿破碎机;规格:DN300;接触物料材质:S30408;密封形式:气密封;电机防护等级:IP55;电机防腐等级:WF2;绝缘等级:F;电源:AC380V/3P/50Hz;禁铜锌，含浮子流量计及气密封电磁阀。　　锂电负极材料结块打散，冷却釜出口不锈钢破碎机：阀体：SUS304.破碎桨叶：SUS304.外表面：喷砂处理，规格：DN200-PN16(PL)，法兰标准：HG/T20592-2009(B)，国茂齿轮减速机，皖南工频电机1.5KW，二级能效，IP55.轴端气密封配B52调压阀，直连传动。　　Partial customer requirements:　　Material: Anode carbon block, small granular raw material, agglomerated by a certain process of 7-10cm, needs to be broken into small pieces by a stainless steel crushing valve, with a discharge port size of 500 * 500. crushed to about 2-3cm. The motor requires first level energy efficiency and explosion-proof in Wannan, and the reducer is Guomao. The material is stainless steel SUS316.　　Crushed particle size: 2-5cm before crushing, 8mm after crushing; design capacity: 4.5t/h; Drive mode: direct connection; Surface requirements: inner surface polished Ra0.4. outer surface Sa2; Material: Lithium battery Lithium carbonate: 4.5t/h, bulk density 380kg/cm2. D90=13um. Form: Tooth crusher; Specification: DN300; Contact material material: S30408; Sealing form: airtight seal; Motor protection level: IP55; Motor anti-corrosion grade: WF2; Insulation Class: F; Power Supply: AC380V/3P/50Hz; Prohibition of copper and zinc, including float flow meters and gas sealed solenoid valves.　　Lithium battery negative electrode material clumping and breaking, cooling kettle outlet stainless steel crusher: valve body: SUS304. crushing blade: SUS304. outer surface: sandblasting treatment, specification: DN200-PN16 (PL), flange standard: HG/T20592-2009 (B), Guomao gear reducer, Wannan power frequency motor 1.5KW, secondary energy efficiency, IP55. Shaft end gas seal with B52 pressure regulating valve, directly connected transmission.　　我公司专 业生产(B)GFY、YJD系列关风机(关风器)、星型卸料器、DS系列电动锁气器、DN型旋转阀，快开清洗阀、防卡旋转阀、偏置防卡、风送直通式旋转阀、高温高压旋转阀、高温水冷式、刮板式自清洁、钛合金陶瓷碳化钨四氟特氟龙尼龙聚氨酯、破拱机、料仓刮料破拱器、打散破碎阀、螺旋输送机等产品。广泛应用于锂电池、食品、石油化工、制药、淀粉、油脂、化工干燥、粮食、饲料、塑料、除尘、冶金、环保、电子、煤炭、建筑、电力机械等行业设备上。用于固体粒料、粉料、超微粉体在气力输送及管网正负压状态下的卸料。　　Our company specializes in the production of (B) GFY, YJD series air shut-off fans (air shut-off devices), star shaped unloaders, DS series electric air locks, DN type rotary valves, quick opening cleaning valves, anti jamming rotary valves, offset anti jamming, air delivery straight through rotary valves, high temperature and high pressure rotary valves, high temperature water-cooled, scraper self-cleaning, titanium alloy ceramic tungsten carbide PTFE PTFE nylon polyurethane, arch breaking machines, silo scraper crushers, fragmentation valves, screw conveyors and other products. Widely used in equipment for industries such as lithium batteries, food, petrochemicals, pharmaceuticals, starch, oils, chemical drying, grain, feed, plastics, dust removal, metallurgy, environmental protection, electronics, coal, construction, and power machinery. Used for unloading solid granules, powders, and ultrafine powders under pneumatic conveying and positive and negative pressure in pipeline networks.

　　刚性叶轮给料机俗称卸料器，又叫卸灰阀。主要适用于发电厂、水泥厂、化工厂等行业除尘灰尘清理和包装机及专 业输送配料系统中，作为输送干燥粉状物料时锁气或定量给料用，也可用于除尘器及空气预热器的灰斗下出灰，其结构简单，性能稳定，操作维修方便，是输送、卸料、配料系统中理想的配套件。　　1、结构紧凑：采用行星转动原理、纯铜电机，输入输出在同一轴线上，而且有与电机直联一体的独特性，体积小，重量轻，因而结构紧凑造型美观新样。　　2、耐磨性高：运行可靠平稳，噪音低，故障少，寿命长，耐磨性高。　　3、过载能力强：卸料器具有过载能力强，耐冲击惯性力矩小，适用于启动频繁和正反转。　　4、使用寿命长：轴承、齿箱、远离阀体避免高温灰尘的影响，前后密封性能好，防止灰尘外泄，延长机动件，润滑系统的使用寿命。　　5、支持定制/替代进口品牌：用户如有特殊规格要求，可以按照客户要求定做。　　常州同得利机械厂拥有多年的研发生产/定制卸料阀旋转阀的经验，秉承质量第 一、用户至 上的原则。我们的旋转阀能够处理锂电池、钢厂、电厂、水泥、矿山、环保、塑料、化工、食品和医药等行业的各种颗粒、片状、块状物料、粉料、超微粉体等。　　The rigid impeller feeder is commonly known as the unloader, also known as the ash discharge valve. It is mainly suitable for dust removal, cleaning, packaging machines, and professional conveying and batching systems in industries such as power plants, cement plants, and chemical plants. It is used for air locking or quantitative feeding when conveying dry powder materials. It can also be used for ash discharge under the ash hopper of dust collectors and air preheaters. Its structure is simple, performance is stable, and operation and maintenance are convenient. It is an ideal supporting component in conveying, unloading, and batching systems.　　1. Compact structure: Adopting the principle of planetary rotation and a pure copper motor, the input and output are on the same axis, and it has the unique feature of being directly connected with the motor. It has a small volume and light weight, resulting in a compact and beautiful design.　　2. High wear resistance: reliable and stable operation, low noise, few faults, long service life, and high wear resistance.　　3. Strong overload capacity: The unloader has strong overload capacity, low impact resistance inertia moment, and is suitable for frequent starting and forward and reverse rotation.　　4. Long service life: bearings, gearboxes, and valves are kept away from the valve body to avoid the influence of high temperature dust. The front and rear sealing performance is good, preventing dust leakage and extending the service life of motor parts and lubrication systems.　　5. Support customization/replacement of imported brands: If users have special specifications, they can customize according to customer requirements.　　Changzhou Tongdeli Machinery Factory has many years of experience in research and development, production, and customization of discharge valve rotary valves, adhering to the principle of quality first and customer first. Our rotary valve can handle various types of particles, flakes, blocks, powders, and ultrafine powders in industries such as lithium batteries, steel mills, power plants, cement, mines, environmental protection, plastics, chemicals, food, and pharmaceuticals.

　　料仓为钛材，涡轮刮料器配置的刮料杆长度需≥600mm，主体材质使用316L不锈钢材质，涡轮刮料器需配置下方变径法兰组件(使用316L不锈钢材质)，变径后的法兰规格与原料仓的法兰规格一致(PN25 DN100 FM凹面 HG/T20592-2009 B系列)，提供涡轮刮料器的安装螺栓螺母(材质A193.B8M Cl.2/A194-8)。物料特性：物料为强碱性，松散堆密度受到破碎粒度影响，范围为0.09~0.4t/m3.粒度越细堆密度越小;料仓物料蕞高堆1500mm高。其他要求：涡轮刮料器需配置防爆电机，防爆等级Ex d IIB T4.防护等级：IP55.绝缘等级：F，防腐等级：WF2.注意，防爆电机应配置金属格兰头。　　DN100破拱机技术参数：　　1、设备主体材质为316.　　2、焊接型机壳(需要做气密检测)。　　3、配亚德客调压阀。　　4、配接近开关。　　5、增加观察口，可观察破拱物料状况。　　6、电机：0.75kW。　　7、减速机：KAF37系列。　　8、输出转速：约5r/min。　　9、输出扭矩：290Nm。　　10、传动方式：齿轮。　　11、四氟油封*4.　　12、内径φ100.外径φ220mm。　　13、高度165mm。　　14、机壳内型腔气体保压调至0.1~0.2MPa。　　旋转破拱机工作原理：　　安装在料仓底部，电机带动齿轮传动，驱动刮板绕仓壁做圆周运动;刮板在旋转中直接把结拱、粘仓的物料刮下来，物料靠重力顺畅下落，从“中心流”恢复成“整体流”。 和空气炮靠气流冲击、振动器靠仓壁振动不同，它是纯机械破拱，对高湿、高粘物料更直接有效，也不会把物料振实。刮料式对仓壁无振动损伤、噪音低，适合薄壁或对振动敏感的料仓。　　耐高温破拱阀进/出 口法兰尺寸(mm)DN100-PN10;物料温度：200-300℃;输送场合压力80KPa;壳体、旋转内圈座材质310模具铸件，搅拌杆材质310;搅拌杆形式扇形;轴(mm)50mm;密封方式气密封-斯特封;物料接触材质精抛光，表面处理喷砂;重型回转轴承;直连传动;破拱阀转速 (r/min)5 -7转;电机(含配件要求)西门子 2.2KW 粉尘防爆 380V-HZ50;减速机(含配件要求)SEW-K67-70.46-2.2KW。　　工程塑料(聚乙醛、聚酰胺、聚氨酯等)的聚合与反应　　塑料(环氧树脂、聚酰胺、聚酯等)的混炼　　化学产品(密封材料、粉末涂料等)的揉捏　　用于电材料产品的揉捏(电池材料、陶瓷、碳、EMC等)　　常州同得利机械厂拥有多年的研发生产/定制破拱机、卸料阀旋转阀的经验，秉承质量第 一、用户至 上的原则。我们的旋转阀能够处理锂电池、钢厂、电厂、水泥、矿山、环保、塑料、化工、食品和医药等行业的各种颗粒、片状、块状物料、粘料、粉料、超微粉体等。　　The silo is made of titanium material, and the scraper rod length of the turbine scraper should be ≥ 600mm. The main material is made of 316L stainless steel, and the turbine scraper should be equipped with a lower variable diameter flange component (made of 316L stainless steel). The flange specification after variable diameter is consistent with the flange specification of the raw material silo (PN25 DN100 FM concave HG/T20592-2009 B series). Installation bolts and nuts (material A193. B8M Cl.2/A194-8) for the turbine scraper are provided. Material characteristics: The material is strongly alkaline, and the loose bulk density is affected by the crushing particle size, ranging from 0.09 to 0.4 t/m3. The finer the particle size, the lower the bulk density; The maximum height of the material in the silo is 1500mm. Other requirements: The turbine scraper needs to be equipped with an explosion-proof motor, explosion-proof level Ex d IIB T4. protection level IP55. insulation level F, and anti-corrosion level WF2. Note that explosion-proof motors should be equipped with metal gland heads.　　Technical parameters of DN100 arch breaking machine:　　1. The main material of the device is 316.　　2. Welded casing (requires air tightness testing).　　3. Equipped with Yadeke pressure regulating valve.　　4. Equipped with proximity switch.　　5. Add observation ports for observation　　6. Motor: 0.75kW.　　7. Gearbox: KAF37 series.　　8. Output speed: about 5r/min.　　9. Output torque: 290Nm.　　10. Transmission mode: gear.　　11. PTFE oil seal * 4　　12. The inner diameter is 100mm and the outer diameter is 220mm.　　13. Height 165mm.　　14. Adjust the gas pressure inside the casing cavity to 0.1~0.2MPa.　　Working principle of rotary arch breaking machine:　　Installed at the bottom of the silo, the motor drives the gear transmission to drive the scraper to make circular motion around the silo wall; The scraper directly scrapes off the arched and stuck materials during rotation, and the materials fall smoothly by gravity, returning from the "center flow" to the "overall flow". Unlike air cannons that rely on airflow impact and vibrators that rely on chamber wall vibration, it is a pure mechanical arch breaking machine that is more direct and effective for high humidity and high viscosity materials, and does not compact the materials. Scraping type has no vibration damage to the warehouse wall, low noise, and is suitable for thin-walled or vibration sensitive silos.　　High temperature resistant arch breaking valve inlet/outlet flange size (mm) DN100-PN10; Material temperature: 200-300 ℃; The pressure in the conveying environment is 80KPa; Shell, rotating inner ring seat material 310 mold casting, mixing rod material 310; The mixing rod is fan-shaped in shape; Axis (mm) 50mm; Sealing method: gas seal - seal; Fine polishing of materials in contact with materials, surface treatment by sandblasting; Heavy duty rotary bearings; Direct transmission; The speed of the arch breaking valve (r/min) is 5-7 revolutions per minute; Motor (including accessory requirements) Siemens 2.2KW dust explosion-proof 380V-HZ50; Gearbox (including accessory requirements) SEW-K67-70.46-2.2KW.　　Changzhou Tongdeli Machinery Factory has many years of experience in research and development, production/customization of arch breaking machines and discharge valve rotary valves, adhering to the principle of quality first and customer first. Our rotary valves are capable of handling various types of particles, flakes, blocks, adhesives, powders, ultrafine powders, etc. in industries such as lithium batteries, steel mills, power plants, cement, mining, environmental protection, plastics, chemical, food, and pharmaceuticals.

　　螺旋输送机又称为倾斜螺旋输送机、‌管式螺旋输送机、‌移动螺旋输送机、‌绞龙输送机或蛟龙输送机。　　螺旋输送机适应工况:　　主要用于输送颗粒状、粉状和小块物料，不适用于输送黏性大，易结块，易变质的物料，因为这些物料在输送时会粘结在螺旋叶片上，并随着旋转而不向前移动，或者在吊轴处形成物料的堵塞，而使螺旋输送机不能正常工作。　　螺旋输送机的工作原理：　　螺旋输送机的工作原理是利用物料的重力及其与槽体壁所产生的摩擦力。物料在中间轴承的运移是依靠后面前进着的物料的推力。所以，物料在输送机中的运送，完全是一种滑移运动。        【槽状螺旋输送机】　　《磨粉用槽式螺旋输送机-为磨粉机而设计》　　槽式螺旋输送机主要用于面粉研磨行业，尤其是输送谷粒、面粉和糠类副产品。螺旋输送机由碳钢制成，其表面经过食品级别的处理。还配备有齿轮减速箱和电机。可以提供经认证的防爆型号。【电话/微信咨询：陈经理18068546632】　　《不锈钢槽式螺旋输送机》　　标准 304L 或 316L 不锈钢设计，带有外部可调轴承密封件(填料密封、空气净化或气体净化密封等)的尾部轴承组件。有轻型和中型两种，所有产品均有防爆型号。【电话/微信咨询：陈经理18068546632】　　《管型螺旋输送机》　　轻载重型主要用于面粉和面粉研磨副产品的进料和输送。中等载重型主要用于动物研磨饲料产品如谷物、粗粉以及研磨副产品的输送。一般而言，管状螺旋输送机和喂料机在应用中能够减少物料残余量和保持物料颗粒原始尺寸。【电话/微信咨询：陈经理 18068546632】　　《槽式螺旋输送机》　　粉末喷涂，螺旋叶片焊接在中心管上，槽体有标准的法兰连接截面，标准长度。槽状螺旋输送机可为输送粉末或颗粒材料提供多种解决方案。宠物食品、塑料加工、肥皂、洗衣粉和清洁剂加工、动物饲料加工、木材加工、化学品、环境技术、水泥、石灰和石膏加工以及矿业。【电话/微信咨询：陈经理 18068546632】　　《动物副产品螺旋输送机》　　槽式螺旋输送机由碳钢制成，并且经过合适的表面处理(主要经过热镀处理)。配有满足需求的齿轮减速箱和电机。槽状螺旋输送机采用不间断运行设计，用于输送屠宰业副产品，比如骨头(整块或碾碎)、蹄、头或肥肉。【电话/微信咨询：陈经理 18068546632】　　《锥形单轴螺旋喂料机》　　锥形单轨螺旋喂料机主要用于面粉加工厂，拥有两个锥形入口螺旋和套管，确保同步卸料和喂料。减少了物料在进料槽的残留。锥形螺旋(方形截面)和槽体由碳钢制成，恒定的喂料速度，坚固设计，高卸料效率。【电话/微信咨询：陈经理 18068546632】　　《锥形双轴螺旋喂料机》　　双轴螺旋喂料机对于要求极高 效地从料箱或料斗卸料/喂料的用户而言是不错的选择。设计用于装卸非同质材料(木、碎屑、纸等)、面粉加工业材料(糠、面粉等)以及挂料材料(如锯屑、大豆等)。喂料面积大，避免了桥接，避免了偏析，即使是难于处理的物料也能保证持续喂料，可靠恒定的喂料速度，高度自清理，槽体清理方便，可以提供防爆型螺旋喂料机。【电话/微信咨询：陈经理 18068546632】　　《高温螺旋输送机》　　超重型槽式螺旋输送机或喂料机专为中高温和高温应用设计。高温螺旋输送机由碳钢或不锈钢制成，经过适当的表面处理。可完全满足输送或喂料要求，尤其是铸造厂、钢铁厂,炼钢厂、发电厂(粉煤灰处理)或干燥设备中的再生砂。【电话/微信咨询：陈经理 18068546632】　　《新拌混凝土用螺旋输送机》　　在混凝土预制行业中，输送机用于将新拌混凝土从浆叶式搅拌机输送到模子中。而以前的皮带输送机则有可能导致混凝土分离。为了保持混凝土均匀和减少驱动力，可以调整进料口部位的混合桨。通过调整桨的角度，可以改变混凝土的生产率。橡胶制槽底板的柔韧性使得螺旋与槽体之间的大块物料不会堵塞在槽体内。当槽底板磨损后，可以快速开合以进行清理和更换。【电话/微信咨询：陈经理 18068546632】                【管状螺旋输送机】　　《管式螺旋输送机》　　管状螺旋输送机和喂料机系统用途极广，可为输送粉末或颗粒材料提供各种标准的解决方案。可为各项应用提供不同型号的输送机或喂料机，比如混凝土生产(适用粉媒灰、填料粉尘、硅粉)、预混合建筑材料(干石膏、沙、水泥、添加剂)、玻璃加工(碳酸钙、苏打、沙等)、铸造厂(沙、膨润土)等。【电话/微信咨询：陈经理 18068546632】　　《不锈钢管式螺旋输送机》　　标准304L或316L不锈钢设计，不锈钢管状螺旋输送机为输送或喂入粉末或颗粒材料提供各种解决方案。对使用环境的要求：环境对物料无任何污染、绝 对清洁、绝 对防腐蚀。管状螺旋输送机尤其适用于环境技术、面粉和动物饲料加工、食品加工和包装、塑料和化学品以及医药行业。【电话/微信咨询：陈经理 18068546632】　　《食品级不锈钢管式螺旋输送机》　　不锈钢管式螺旋输送机是食品行业前沿的解决方案。确保设备的组件表面平滑，这就是物料残留极小的原因。适用于需物料不受任何污染和要求绝 对清洁以及耐腐蚀的应用。标准304L或316L不锈钢设计，易于维护，从管状输送机中取出螺旋方便。【电话/微信咨询：陈经理 18068546632】　　《超低物料残留管式螺旋输送机》　　内部无螺钉螺栓，方便输送机零件清理，同时降低了物料残留。残留在更大程度上是由螺旋轴线在外管底部方向的微小偏移所产生的二者之间的间隔引致。螺旋叶片和槽体的间隙不超过5mm。另一方面，螺旋与底板之间的轴向间隙为2.5mm。适合用于散装物料的输送和喂料，主要用于食品行业、塑料和化学制品处理，以及特定限 制范围内的制药行业。表面光滑(内部无螺栓螺母)可以方便、快速地从管式输送机壳中抽出螺旋。【电话/微信咨询：陈经理 18068546632】　　《单轴螺旋喂料机》　　一些粉末或颗粒材料流动性极差，以致无法用圆形排放孔式的锥体装置将其存储于料仓中，需要用更陡峭的椎体装置及椭圆形排放口将其存储于料仓中。单轴螺旋喂料机与料仓出口的形状相契合。料槽部分与管状部分相连接，可有效喂入材料以便进一步加工。有防爆型号可选。【电话/微信咨询：陈经理 18068546632】　　《精确喂料螺旋输送机》　　低转速 (SPS)，防磨材料制成的螺旋，主螺旋与精确喂料螺旋之间连接料斗，范围宽广，可以用于各种物料，包括高磨损性物料。精确喂料螺旋主要用作输送量大的主螺旋喂料机的补充。在接近设定的喂料量时，用接近开关将主螺旋喂料机关闭，进而用法兰连接在主螺旋出料端下方的精确喂料螺旋进行精确喂料，将物料从主螺旋的出料口输送到重量料斗内。【电话/微信咨询：陈经理 18068546632】　　《重载型管式螺旋输送机》　　主要用于间歇作业和连续作业情况，产品耐用和易于更换易坏零件。附加的进出料口，附加的观察窗。这类螺旋输送机常见于矿物加工、玻璃加工、铸造厂、水泥厂、石膏和石灰生产等应用以及矿业中。【电话/微信咨询：陈经理 18068546632】　　《水泥螺旋喂料机》　　主要用于下列物料的喂料和输送：混凝土生产厂的水泥和类似水泥的粉料，也可以用于其它建筑材料的加工过程中。粉末喷涂，外管包括焊接末端法兰、进料口、出料口，观察窗在进料口和中间吊挂轴承的下面。耐用，维护方便，进料口和出料口通用，安装快，高性价比。【电话/微信咨询：陈经理 18068546632】　　《容积计量式水泥螺旋喂料机》　　专为容积计量喂入水泥或类似材料而设计，产品配备大型入口料斗。压力开关一检测到进口料斗内无物料，ESV螺旋喂料机便会停止工作。【电话/微信咨询：陈经理 18068546632】　　《管式带状叶片螺旋喂料机》　　带式螺旋叶螺旋喂料机确保在特殊的石灰投加设备中将石灰均匀卸下和喂入溶解设备或微型喂料设备。考虑到实际应用情况，通常配有变速驱动。进料口下设有标准观察窗，进料速度从70到4500升/小时，物料流动平缓，喂料精确度高。【电话/微信咨询：陈经理 18068546632】　　《污泥用垂直螺旋输送机》　　有效输送不同种类的污泥　　当前，淤泥处理技术需要投入越来越多的相关设备设施，例如：搅拌机、污水处理设备等。对这些设备的喂料和卸料需要将淤泥提升到较高位置。保证了恒定的喂料速度和淤泥的进一步混合。考虑到腐蚀或磨损，为确保螺旋输送机耐用，可以选择碳钢或不锈钢材料，无味操作，清洗时间短，高性价比。【电话/微信咨询：陈经理 18068546632】　　《垂直螺旋输送机》　　垂直螺旋输送机系统包括两部分：一个水平螺旋喂料机，用于从料斗、料仓或其他的喂料机、输送机中接收物料;一个垂直螺旋输送机，将物料提升到一定高度。物料可以被卸载到一个高处料斗、一个或多个箱柜或料仓，或者传递到其他的输送机或输送系统。经过特殊设计的制造件、螺旋和轴承组件使得系统维护方便。【电话/微信咨询：陈经理 18068546632】　　《填料粉末螺旋喂料机和输送机》　　专为处理沥青厂的填料尘埃　　填料粉末螺旋喂料机和输送机专为满足沥青行业的主要要求而设计，用于固定式沥青厂喂入和输送冷热填料粉末。一端连接中 央粉末过滤器，另一端连接混合设备的存储料仓及称重料斗。连接法兰，可调节卡箍式管支架。【电话/微信咨询：陈经理 18068546632】　　《无轴螺旋输送机》　　输送不容易处理的物料　　物料靠无轴的重负载螺旋叶片输送，无轴螺旋叶片在槽体中被放置在特殊材料制成的耐磨衬垫上。可以纵向拆分的U型槽板由碳钢或304L/316L不锈钢制成。用于输送城市固体废料、筛渣和漂浮物、脱水淤渣、稠化淤渣或调和淤渣、包装食品、乳脂或膏以及肉类、鱼类、果蔬加工废料。应用的主要领域：一般用于废水处理、制糖厂废料、鱼类工业、固体废料处理、果蔬加工厂、饮料工业、造纸业、化工、食品业、肉类加工厂、屠宰场、餐馆、食堂和餐饮等。【电话/微信咨询：陈经理 18068546632】      《扫二维码-添加 陈经理 微信-咨询螺旋输送机》
