电动锁气器/锁气阀适用于火力发电厂除尘器、空气预热器，省煤器等设备的出料口，或干灰输送管道中，作锁气及均匀给料。也可用于化工厂、水泥厂、粮食加工厂部门的气力运输管道中。　　电动锁气器/锁气阀结构与型式：　　主要结构有壳体、转子、传动结构(摆线针轮减速机、电动机)。【电话/微信咨询：陈经理18068546632】　　装置型式主要有两种：　　转动机构与转子直线联接，一字排开--直连式。　　转动机构与转子用链条搭接--平行轴线式。　　在直连式中，又可细分为带角铁支架以配装卧式减速机(加注B)以及经联轴节直接联接立式减速机的型式(加注A)　　备注：可定制非标型。【电话/微信咨询：陈经理18068546632】        《扫二维码-添加 陈经理 微信-咨询电动锁气器/锁气阀》　　Electric air lock/air lock valve is suitable for the discharge ports of dust collectors, air preheaters, economizers and other equipment in thermal power plants, or in dry ash conveying pipelines, for air lock and uniform feeding. It can also be used in pneumatic transportation pipelines of chemical plants, cement plants, and grain processing plants.　　Electric air lock/lock valve structure and type:　　The main structures include shell, rotor, and transmission structure (cycloidal pinwheel reducer, electric motor).　　There are two main types of devices:　　The rotating mechanism is linearly connected to the rotor, arranged in a straight line - direct connection.　　The rotating mechanism and rotor are overlapped with chains - parallel axis type.　　In direct connection, it can be further divided into two types: those with angle iron brackets to install horizontal reducers (note B) and those directly connected to vertical reducers through couplings (note A)　　Note: Non standard models can be customized.

　　关风机又称卸料器、星型卸料阀、旋转阀、旋转卸料阀、旋转给料器、锁气阀、电动锁气器、旋转供料阀，通常星型卸料器的结构是由带有数片叶片的转子叶轮、壳体、密封件及减速器、电动机等组成。【电话/微信咨询：陈经理18068546632】　　T(B)GFY型不锈钢强力组合关风机系列：　　压力范围：0.5kg/cm²系统压力或压差。　　关风机入口/出口：入口为圆口并配有透明视窗，以便观察物料的流动状况;出口为方形，增大了出口面积使物料顺利排出。　　普通型：结构紧凑，占用空间小。　　轴承外置式：有效的防止粉尘侵入轴承。　　驱动方式：马达直连驱动为主。　　动力配置：摆线针轮减速机、Y系列电机(可按需方指定动力配置)。　　材质选项：碳钢、铸铁、不锈钢、铝合金、钛合金、四氟、陶瓷、PPC系列、尼龙、特氟龙等。【电话/微信咨询：陈经理18068546632】　　常州同得利机械厂拥有多年的研发生产/定制关风机，卸料阀旋转阀的经验，秉承质量第 一、用户至 上的原则。我们的关风机/旋转阀能够处理锂电池、钢厂、电厂、水泥、矿山、环保、塑料、化工、食品和医药等行业的各种颗粒、片状、块状物料、粘料、粉料、超微粉体等。【电话/微信咨询：陈经理18068546632】《扫二维码-添加 陈经理 微信-咨询T(B)GFY型不锈钢关风机/关风器》　　Shutter fan, also known as unloader, star shaped unloader valve, rotary valve, rotary unloader valve, rotary feeder, air lock valve, electric air lock valve, rotary feeding valve, is usually composed of a rotor impeller with several blades, a housing, seals, a reducer, an electric motor, etc.　　T (B) GFY stainless steel strong combination fan series　　Pressure range: 0.5kg/cm ² system pressure or pressure difference.　　Entrance/Exit: The entrance is circular and equipped with a transparent window for observing the flow of materials; The exit is square, increasing the exit area to facilitate the smooth discharge of materials.　　Ordinary type: compact structure and small space occupation.　　External bearing: effectively prevents dust from entering the bearing.　　Drive mode: Mainly driven by direct motor connection.　　Power configuration: Cycloid pinwheel reducer, Y series motor (power configuration can be specified by the demand).　　Material options: carbon steel, cast iron, stainless steel, aluminum alloy, titanium alloy, PTFE, ceramic, PPC series, nylon, PTFE, etc.

　　关风机入口/出口：入口为圆口并配有透明视窗，以便观察物料的流动状况;出口为方形增大了出口面积使物料顺利排出。　　普通型：结构紧凑，占用空间小。　　轴承外置式：防止粉尘侵入轴承、增大适应温度的范围。　　轴承外置式安装、性能优异。　　驱动方式：马达直联驱动为主、链驱动。　　关风机材质：碳钢、铸铁、不锈钢、陶瓷、尼龙、四氟、特氟龙、钛合金、铝合金、各种合金系列等。【电话/微信咨询：陈经理18068546632】　　关风机的安装：　　1、检查产品经过运输或贮藏后是否损坏锈蚀;叶轮应能灵活转动。　　2、与关风器的结合平面应平整，平面度不大于0.5mm，以免机壳变形引起故障。　　3、关风器安装后要校正水平，紧固固定螺栓，叶轮能灵活转动无障碍。【电话/微信咨询：陈经理18068546632】　　我公司专 业生产(B)GFY、YJD系列关风机(关风器)、星型卸料器、DS系列电动锁气器、DN型旋转阀，快开阀、清洁阀、风送式旋转阀等产品。广泛应用于锂电池、粮食、饲料、石油化工、制药、淀粉、油脂、化工干燥、塑料、除尘、冶金、环保、电子、煤炭、建筑、电力机械等行业设备上。用于固体粒料、粉料、超微粉体在气力输送及管网正负压状态下的卸料。           《扫二维码-添加 陈经理 微信-咨询风送式关风机》　　Shut down the inlet/outlet of the fan: The inlet is circular and equipped with a transparent window for observing the flow of materials; The square shape of the outlet increases the outlet area and facilitates the smooth discharge of materials.　　Ordinary type: compact structure and small space occupation.　　External bearing: prevents dust from entering the bearing and increases the temperature adaptability range.　　External installation of bearings, excellent performance.　　Drive mode: mainly direct motor drive, chain drive.　　Material of the fan: carbon steel, cast iron, stainless steel, ceramic, nylon, PTFE, PTFE, titanium alloy, aluminum alloy, various alloy series, etc.　　Installation of shutdown fan:　　1. Check whether the product is damaged or corroded after transportation or storage; The impeller should be able to rotate flexibly.　　2. The joint plane with the air conditioner should be flat, with a flatness of no more than 0.5mm, to prevent deformation of the casing and potential malfunctions.　　3. After the installation of the air conditioner, it is necessary to calibrate the level, tighten the fixing bolts, and ensure that the impeller can rotate flexibly without obstacles.

　　【偏置式星型卸料器系列】　　适用于≤2kg/cm²系统压力或压差。　　设置排气口(正压输送时选用)将叶轮旋转带出的气体通过排气口送至排气装置，提高填充效率。　　偏置卸料器防切料入口设计，即便上游充满物料也可安全启动。　　偏置式进出料口设计，减少了物料的破碎与损坏。【电话/微信咨询：陈经理18068546632】　　轴承外置式安装、经久耐用、性能优异。　　提供链驱动、直联驱动多种安装方式。　　根据需求配置减速机电机。　　偏置卸料器材质主要有：铸钢、不锈钢、合金系列等。　　壳体及主要零部件采用精密铸造，外形美观;　　高强度的阀体及轴，可承受高压且运转平稳;　　特殊防卡料设计，避免运转中粒子剪断现象;【电话/微信咨询：陈经理18068546632】　　常州同得利机械厂拥有多年的研发生产/定制卸料阀旋转阀的经验，秉承质量第 一、用户至 上的原则。我们的旋转阀能够处理锂电池、钢厂、电厂、水泥、矿山、环保、塑料、化工、食品和医药等行业的各种颗粒、片状、块状物料、粘料、粉料、超微粉体等。       《扫二维码-添加 陈经理 微信-咨询偏置式卸料器》　　Offset star shaped unloader series　　Suitable for system pressures or pressure differentials of ≤ 2kg/cm ².　　Set up an exhaust port (selected for positive pressure conveying) to send the gas carried out by the impeller rotation to the exhaust device through the exhaust port, improving the filling efficiency.　　The offset unloader is designed with an anti cutting material inlet, which can be safely started even if the upstream is filled with material.　　The offset inlet and outlet design reduces material breakage and damage.　　External installation of bearings, durable and excellent performance.　　Provide multiple installation methods for chain drive and direct drive.　　Configure the gearbox motor according to the requirements.　　The materials of offset unloaders mainly include cast steel, stainless steel, alloy series, etc.　　The shell and main components are precision cast, with a beautiful appearance;　　High strength valve body and shaft, capable of withstanding high pressure and running smoothly;　　Special anti jamming material design to avoid particle shearing during operation.

　　星型卸料器/卸料阀是气力输送系统中的关键设备。也是除尘和加料系统的常用设备。根据特性、用途和使用条件的不同，星型卸料器有多种结构型式，星型卸料器的选型要根据被输送物料的特性如堆积密度、物料温度、吸潮性、含水量、粒径、流动性、硬度、腐蚀性等来决定的。　　常州同得利机械厂主要制造适用于粘性的，含坚硬杂质的以及高温高压或高真空情况下使用的特殊结构的星型卸料器。以及超小尺寸的卸料器，都是非常规结构特殊非标定制。【电话/微信咨询：陈经理 18068546632】　　不锈钢卸料器可应用于食品等有高卫生要求的场合，拆卸方便，易于进行清理工作，符合高要求的卫生标准。操作方便，无死点。     《扫二维码-添加 陈经理 微信-咨询食品级卸料阀》　　Star shaped unloader/discharge valve is a key equipment in pneumatic conveying systems. It is also a commonly used equipment for dust removal and feeding systems. According to different characteristics, purposes, and usage conditions, star shaped unloaders have various structural types. The selection of star shaped unloaders should be determined based on the characteristics of the conveyed material, such as bulk density, material temperature, moisture absorption, moisture content, particle size, flowability, hardness, corrosiveness, etc.　　Changzhou Tongdeli Machinery Factory mainly manufactures star shaped unloaders with special structures suitable for viscous, hard impurity containing, and high-temperature, high-pressure, or high vacuum conditions. And the ultra small size unloaders are all customized with unconventional structures and special non-standard designs.　　Stainless steel unloaders can be used in places with high hygiene requirements such as food. They are easy to disassemble and clean, meeting high hygiene standards. Easy to operate, no dead spots.

　　快速清洗型旋转阀广泛应用于食品、医药、化工对卫生高要求场合，以及更换物料频繁需要清理卸料的系统。按操作形式可分为滑杆式和快开式，易于快速清理叶腔中粘性物料，安装方便。　　1.滑杆式旋转阀：清洗前的拆卸。松开活动瑞盖上的螺旋手柄，沿柱将瑞盖和转子一起拉出，松开轴端的螺旋手柄，取出转子。　　2.快开门式旋转阀：松开固定螺栓，打开端盖门，抽出转子，清洗后转子推入壳体内，旋紧定位螺栓。【电话/微信咨询：陈经理 18068546632】　　结构紧凑：采用行星转动原理、纯铜电机，输入输出在同一轴线上，而且有与电机直联一体的独特性，体积小，重量轻，因而结构紧凑造型美观新样。　　耐磨性高：运行可靠平稳，噪音低，故障少，寿命长，耐磨性高。　　过载能力强：卸料器具有过载能力强，耐冲击惯性力矩小，适用于启动频繁和正反转。【电话/微信咨询：陈经理 18068546632】           《扫二维码-添加 陈经理 微信-咨询不锈钢清洗型旋转阀》　　Quick cleaning rotary valves are widely used in food, medicine, chemical industries with high hygiene requirements, as well as systems that require frequent cleaning and unloading of materials. According to the operating form, it can be divided into sliding rod type and quick opening type, which is easy to quickly clean viscous materials in the blade cavity and easy to install.　　1. Sliding rod rotary valve: disassembly before cleaning. Release the spiral handle on the activity cover, pull out the cover and rotor together along the column, release the spiral handle on the shaft end, and remove the rotor.　　2. Quick opening rotary valve: Loosen the fixing bolts, open the end cover door, extract the rotor, clean it, push the rotor into the housing, and tighten the positioning bolts.　　Compact structure: Adopting the principle of planetary rotation and a pure copper motor, the input and output are on the same axis, and it has the unique feature of being directly connected to the motor. It is small in size and light in weight, resulting in a compact structure and beautiful appearance.　　High wear resistance: reliable and stable operation, low noise, few faults, long service life, high wear resistance.　　Strong overload capacity: The unloader has strong overload capacity, low impact resistance inertia moment, and is suitable for frequent starting and forward and reverse rotation.

【风送滑杆式旋转阀】耐高温主要结构：外壳金属;物料接触部分：内衬陶瓷(也可碳化钨、尼龙、四氟、特氟龙、聚氨酯、不锈钢、合金等)。主要用于化工、食品、药材、锂电原料输送。针对物料粘接，风力直吹转子清理。快拆清理，快速复位。轴承外置式：有效的防止粉尘侵入轴承，增大设备适应较高温度的使用范围。驱动方式：链驱动/马达直连驱动口。【电话/微信咨询：陈经理18068546632】动力配置：摆线针轮减速机、Y系列电机(可按需方指定动力配置)。主要材料：不锈钢304-316.陶瓷氧化铝，碳钢、铸铁、不锈钢、铝合金、钛合金、陶瓷系列等。          《扫二维码-添加 陈经理 微信-咨询风送滑杆式旋转阀》 Wind driven sliding rod rotary valveMain structure: metal shell; Material contact part: lined with ceramics (also tungsten carbide, nylon, PTFE, PTFE, polyurethane, stainless steel, alloys, etc.).Mainly used for transporting chemical, food, medicinal materials, and lithium battery raw materials.For material bonding, clean the rotor with direct wind blowing. Quick disassembly and cleaning, quick reset.External bearing: effectively prevents dust from entering the bearing and increases the equipment's adaptability to higher temperatures.Drive mode: chain drive/motor directly connected to the drive port.Power configuration: Cycloid pinwheel reducer, Y series motor (power configuration can be specified by the demand).Main materials: stainless steel 304-316. ceramic alumina, carbon steel, cast iron, stainless steel, aluminum alloy, titanium alloy, ceramic series, etc.

【风送式卸料阀】正压输送压力范围：2kg/cm²系统压力或压差。增大入口/出口：正方形，没有截面尺寸对料流的限 制从而可达高产量。普通型：结构紧凑，占用空间小。轴承外置式：有效的防止粉尘侵入轴承，增大设备适应较高温度的使用范围。【电话/微信咨询：陈经理18068546632】驱动方式：链驱动/马达直连驱动口。动力配置：摆线针轮减速机、Y系列电机(可按需方指定动力配置)。材质选项：碳钢、铸铁、不锈钢、铝合金、钛合金、陶瓷系列等。【电话/微信咨询：陈经理18068546632】风送式卸料阀主要用于化工、食品、药材、原料输送。           《扫二维码-添加 陈经理 微信-咨询风送卸料阀》Pressure range: 2kg/cm ² system pressure or pressure difference.Increase inlet/outlet: Square, without cross-sectional size restrictions on material flow, thus achieving high yield.Ordinary type: compact structure and small space occupation.External bearing: effectively prevents dust from entering the bearing and increases the equipment's adaptability to higher temperatures.Drive mode: chain drive/motor directly connected to the drive port.Power configuration: Cycloid pinwheel reducer, Y series motor (power configuration can be specified by the demand).Material options: carbon steel, cast iron, stainless steel, aluminum alloy, titanium alloy, ceramic series, etc.Pneumatic discharge valves are mainly used for chemical, food, medicinal, and raw material transportation.

一款全尼龙星型旋转阀，相比于传统的304内衬工艺，喷涂碳化钨四氟和陶瓷粉等工艺，全尼龙卸料阀更为优越，它不仅能保证阀的强度和耐磨性，还具备锁风密闭的功能，让物料更流畅，使用更精久。A fully nylon star shaped rotary valve, compared to traditional 304 lining process, spraying tungsten carbide tetrafluoroethylene and ceramic powder processes, the fully nylon discharge valve is superior. It not only ensures the strength and wear resistance of the valve, but also has the function of air locking and sealing, making the material smoother and more durable.这款改性尼龙旋转阀采用了独特的V型结构叶轮片，通过盛料后叶轮以低速旋转的方式，让物料根据自身重力进行卸料，在卸料过程中，物料可以密封，壳体与旋转叶轮之间的间隙，实现了锁气功能，避免了气体泄露的问题，全尼龙旋转阀的两端采用了气密装置，确保了阀的密封性，它的优越性能使得它在锂电/化工/制药行业得到了广泛的应用。【电话/微信咨询：陈经理18068546632】改性尼龙旋转阀主要结构：壳体、叶轮、端盖，采用改性尼龙。主要用于输送锂电池正极材料、磷酸铁锂、三元材料等。特点：改性尼龙比普通尼龙更耐磨、耐高温。【电话/微信咨询：陈经理18068546632】改性尼龙旋转阀技术研发于2016年，批量生产于2018年，2020年更新第4代尼龙星型旋转阀，目前有尼龙星型旋转阀专 利。            《扫二维码-添加 陈经理 微信-咨询产品》This modified nylon rotary valve adopts a unique V-shaped structure impeller blade, which rotates at low speed after feeding, allowing the material to be unloaded according to its own gravity. During the unloading process, the material can be sealed, and the gap between the shell and the rotating impeller achieves gas locking function, avoiding gas leakage problems. The two ends of the all nylon rotary valve are equipped with airtight devices to ensure the sealing of the valve. Its superior performance has made it widely used in the lithium battery/chemical/pharmaceutical industries.The main structure of the modified nylon rotary valve is the shell, impeller, and end cover, which are made of modified nylon.Mainly used for transporting lithium battery cathode materials, lithium iron phosphate, ternary materials, etc.Characteristics: Modified nylon is more wear-resistant and heat-resistant than ordinary nylon.

　　LSY提升式螺旋输送机核心作用是‌利用旋转螺旋叶片在密闭管内推移物料，实现粉体、颗粒及小块状物料的短距离垂直(或大倾角)高 效输送‌，兼具空间节省与防尘密封优势 。‌‌LSY提升式螺旋输送机主要为垂直⊥或大倾角(通常>45°)，需配合水平螺旋输送机以保证进料压力 。　　The core function of LSY lifting screw conveyor is to use rotating spiral blades to push materials inside a closed pipe, achieving efficient short distance vertical (or large inclination angle) transportation of powders, particles, and small block materials, with the advantages of space saving and dust-proof sealing. The LSY lifting screw conveyor is mainly vertical or with a large inclination angle (usually>45 °), and needs to be matched with a horizontal screw conveyor to ensure the feeding pressure.　　LSY提升式螺旋输送机：　　结构组成：主轴、螺旋叶片、料槽、机盖、驱动装置等。　　特点：物料定位输送;透明视窗查看物料流动。　　行业应用：食品、制药、化工、锂电新能源行业、水泥、冶金、矿山、环保、钢厂、电厂等。　　规格参考‌：螺旋直径有LSY80、LSY100、LSY150、LSY200、LSY250、LSY300、LSY400、LSY500、LSY600、LSY800、LSY1000、LSY1200等规格，或者非标定制;输送量0.1m³/h~300m³/h。　　材质：陶瓷、碳化钨、尼龙、四氟、特氟龙、钛合金、铝合金、不锈钢、碳钢等。　　304(06Cr19Ni10)、316(06Cr17Ni12Mo2)、321(06Cr18Ni11Ti)、310S(06Cr25Ni20)、双相不锈钢2205(022Cr23Ni5Mo3N)、2507(022Cr25Ni7Mo4N)　　LSY提升式螺旋输送机适用于流动性好、干燥的‌粉体、颗粒及小块状物料‌，不建议输送粘性大、易结块或易变质物料 。　　提升式螺旋轴高速旋转(转速高于水平式螺旋)，物料受离心力作用紧压机壳内壁，产生足够摩擦阻力阻止其随叶片同步旋转 。全封闭管/槽结构防止粉尘外溢、物料受潮或外界污染。部分机型可在输送过程中同步进行冷却或电加热作业 。结构类型‌：分为有轴螺旋(适合干粉)和无轴螺旋(适合稍粘物料)，外壳多为 U 型或管式 。　　垂直螺旋输送机的螺旋体的转速比普通螺旋输送机的要高，输送的物料在离心力的作用下，与料槽间产生了摩擦力，该摩擦力阻止物料随螺旋叶片一起旋转并克服了物料下降的重力，从而实现了物料的垂直输送。垂直⊥输送量小，输送高度小，转速较高，能耗大。适宜输送流动性好的粉末状物料，主要用于提升物料，提升高度一般不大于10米。　　LSY提升式输送机生产厂家采购指南：　　在采购该设备时需将物料的颗粒度大小、物料密度、输送量、输送距离与输送角度告知我们同得利生产厂家，由我们同得利生产厂家帮您选型，如果您对该参数不了解时，应由厂家委派技术人员现场实际测量、设计生产。　　部分客户需求：　　螺旋输送机提升式，物料：磷化铝，密度2.42g/cm3.每小时提升6吨，粉尘防爆电机A20.电机在上部，角度30度，下料口不超过1.5米，进料口口径600mm，提升高度1.5米，筒式螺旋，材质不锈钢，螺旋叶片厚度8-10mm。　　水平螺旋+提升式+旋转阀，DN200 高密封，304材质，物料类型:PA塑料颗粒成品料，堆积密度:0.7g/cm3.单套系统产量:3500kg/h，总产量:按系统数量叠加，输送条件:水平距离≤10m，提升高度s6m。　　提升式螺旋给料机，粉状物料，每小时400-500公斤，堆密度0.6.提升高度2.5m，材质316.　　分配螺旋给料机和星型卸料器：出力8t/h，用于散料和成型料从半地下料斗至带式输送机，从0米至4米高度。螺旋给料机满足≥50kPa密封要求。星型给料机配合螺旋给料机实现双重密封。　　螺旋输送机一个喂料，一个提升式输送，物料：工业盐，输送量3.5t/h，材质不锈钢304.　　主要输送介质:玉米杂质粉末状及灰尘，温度:常温，产能3T/h，304材质，要耐磨性好的，现有的用的GX型时间不长，需要经常更换，磨损严重。　　提升式螺旋上料机，物料粉体，转运砂子，水泥，建筑垃圾等，每次输送量500公斤，提升高度6米。　　破碎阀+提升式螺旋输送机+星型卸料阀，部分物料结块破碎打散后经过筛分，通过提升螺旋输送，到管道罗茨风机吹，输送量3~5t/h左右，密封卸料阀，需要锁气功能。　　螺杆上料机，输送的物料是粉末状和小颗粒状，用于无害化处理。每小时的输送能力是10t。上料螺杆输送机的水平跨度6m，高度提升4m，从地面输送到下一地点。　　水平+垂直螺旋输送机，介质干泥，粉料，需要按图纸定制，出口新加坡，材质SUS304.1000kg/h,DN200.　　风送式旋转阀+提升式螺旋上料机，介质：聚合氧化铝，有气源，每次8吨左右的聚合氯化铝需要输送卸料，输送到料仓，距离大概9米，垂直高度5米左右。　　旋转供料器+水平式螺旋给料机+垂直螺旋，含S02、Nox、粉尘和消石灰粉，输送量:1~2t/h，输送管道DN80.粉尘密度1000kg/m，水平距离4m，垂直高度3m。　　LSY lifting screw conveyor:　　Spiral conveyor lift type, material: aluminum phosphide, density 2.42g/cm3. lifting 6 tons per hour, dust explosion-proof motor A20. motor at the top, angle 30 degrees, discharge port not exceeding 1.5 meters, feed port diameter 600mm, lifting height 1.5 meters, cylindrical spiral, material stainless steel, spiral blade thickness 8-10mm.　　Horizontal spiral+lifting+rotary valve, DN200 high seal, 304 material, material type: PA plastic particle finished material, bulk density: 0.7g/cm3. single system output: 3500kg/h, total output: stacked according to the number of systems, conveying conditions: horizontal distance ≤ 10m, lifting height s6m.　　Structural composition: spindle, spiral blades, material trough, machine cover, driving device, etc.　　Features: Material positioning and conveying; View material flow through a transparent window.　　Industry applications: food, pharmaceutical, chemical, lithium-ion new energy industry, cement, metallurgy, mining, environmental protection, steel mills, power plants, etc.　　Specification reference: Spiral diameter available LSY80、LSY100、LSY150、LSY200、LSY250、LSY300、LSY400、LSY500、LSY600、LSY800、LSY1000、LSY1200 Equal specifications or non-standard customization; The conveying capacity ranges from 0.1m ³/h to 300m ³/h.　　Materials: ceramics, tungsten carbide, nylon, PTFE, PTFE, titanium alloy, aluminum alloy, stainless steel, carbon steel, etc.　　304(06Cr19Ni10)、316(06Cr17Ni12Mo2)、321(06Cr18Ni11Ti)、310S(06Cr25Ni20)、双相不锈钢2205(022Cr23Ni5Mo3N)、2507(022Cr25Ni7Mo4N)　　LSY lifting screw conveyor is suitable for powders, particles, and small pieces of materials with good fluidity and dryness. It is not recommended to transport materials with high viscosity, easy agglomeration, or easy deterioration.　　The elevating spiral shaft rotates at high speed (higher than the horizontal spiral), and the material is tightly pressed against the inner wall of the casing by centrifugal force, generating sufficient frictional resistance to prevent it from synchronously rotating with the blades. The fully enclosed pipe/groove structure prevents dust overflow, material moisture or external pollution. Some models can perform cooling or electric heating operations simultaneously during the conveying process. Structural types: divided into axial spiral (suitable for dry powder) and shaftless spiral (suitable for slightly viscous materials), with the shell mostly being U-shaped or tubular.　　The rotational speed of the spiral body of the vertical screw conveyor is higher than that of the ordinary screw conveyor. Under the action of centrifugal force, the conveyed material generates frictional force between the material and the chute, which prevents the material from rotating together with the spiral blades and overcomes the gravity of the material's descent, thus achieving vertical conveying of the material. Vertical conveying capacity is small, conveying height is small, rotation speed is high, and energy consumption is high. Suitable for conveying powdery materials with good fluidity, mainly used for lifting materials, with a lifting height generally not exceeding 10 meters.　　LSY Lift Conveyor Manufacturer Procurement Guide:　　When purchasing this equipment, you need to inform us, Tongdeli manufacturer, of the particle size, material density, conveying capacity, conveying distance, and conveying angle of the material. Tongdeli manufacturer will help you select the appropriate parameters. If you are not familiar with these parameters, the manufacturer should assign technical personnel to measure, design, and produce on site.　　Partial customer requirements:　　Elevating spiral feeder, powder material, 400-500 kilograms per hour, bulk density 0.6. lifting height 2.5m, material 316.　　Distribution of spiral feeder and star shaped unloader: with an output of 8t/h, used for bulk and formed materials from semi underground hoppers to belt conveyors, from 0 meters to 4 meters in height. The spiral feeder meets the sealing requirement of ≥ 50kPa. The star shaped feeder is paired with a spiral feeder to achieve dual sealing.　　Spiral conveyor with one feeding and one lifting conveyor, material: industrial salt, conveying capacity of 3.5t/h, material: stainless steel 304.　　Main conveying medium: corn impurity powder and dust, temperature: room temperature, production capacity 3T/h, made of 304 material, with good wear resistance. The existing GX type has not been used for a long time and needs to be replaced frequently, resulting in severe wear and tear.　　Lift type spiral feeder, material powder, transport sand, cement, construction waste, etc., with a conveying capacity of 500 kilograms per time and a lifting height of 6 meters.　　Crushing valve+lifting screw conveyor+star shaped discharge valve. Some materials are agglomerated, broken and dispersed, screened, and then transported by lifting screw conveyor to pipeline Roots blower for a conveying capacity of about 3-5 t/h. The discharge valve is sealed and requires air locking function.　　Screw feeder, conveying materials in powder and small particle form, used for harmless treatment. The conveying capacity per hour is 10 tons. The horizontal span of the feeding screw conveyor is 6 meters, and the height is raised by 4 meters to transport from the ground to the next location.　　Horizontal+vertical screw conveyor, medium dry mud, powder, needs to be customized according to the drawings, exported to Singapore, material SUS304. 1000kg/h, DN200.　　Pneumatic rotary valve+lifting spiral feeder, medium: polyaluminum oxide, with gas source, about 8 tons of polyaluminum chloride need to be transported and unloaded each time, transported to the silo, with a distance of about 9 meters and a vertical height of about 5 meters.　　Rotating feeder+horizontal spiral feeder+vertical spiral, containing SO2. NOx, dust and hydrated lime powder, conveying capacity: 1-2 t/h, conveying pipeline DN80. dust density 1000kg/m, horizontal distance 4m, vertical height 3m.
