锂电专用打散阀卸料器，介质性质：粉体/粉料偶尔结块需打散(六氟磷酸锂);常温，设计压力：0.2MPa(G)处理量：蕞大 1.5kg/s，下料量可调节，需控制尾料小方量控制精度;连接方式：DN200法兰连接;阀门壳体：316L不锈钢，转子(叶轮)：316L不锈钢;材质处理：物料接触喷涂碳化钨WC;密封要求：多重密封形式，不允许漏粉与空气接触;吹扫要求：下料管道氮气推动与保护，管道物料需能吹扫清理;减速机SEW，电机SEW或西门子，变频电机，防爆等级 EXdⅡBT4.旋转打散卸料阀变频控制柜，就地 / 远程DCS互锁切换;就地按键启停+变频调速，DCS干接点启停、调速，同步上传运行、故障信号。

　　Lithium battery specific breaking valve unloader, medium properties: powder/occasional clumping of powder needs to be broken up (lithium hexafluorophosphate); At room temperature, design pressure: 0.2MPa (G), processing capacity: maximum 1.5kg/s, adjustable feeding amount, and the precision of controlling the small amount of tail material needs to be controlled; Connection method: DN200 flange connection; Valve housing: 316L stainless steel, rotor (impeller): 316L stainless steel; Material treatment: Material contact spraying tungsten carbide; Sealing requirements: Multiple sealing forms are not allowed to leak powder and come into contact with air; Blowing requirements: The discharge pipeline should be driven and protected by nitrogen gas, and the pipeline materials should be able to be blown and cleaned; Gearbox SEW, motor SEW or Siemens, variable frequency motor, explosion-proof grade EXd Ⅱ BT4. Rotating and dispersing discharge valve variable frequency control cabinet, local/remote DCS interlock switching; On site button start stop+variable frequency speed regulation, DCS dry contact start stop and speed regulation, synchronously uploading operation and fault signals.

　　六氟磷酸锂‌既不是正极也不是负极材料‌，而是锂离子电池‌电解质溶质的核心成分‌，电解液关键原料(无机锂盐)，化学式 LiPF₆，在有机溶剂中解离提供锂离子，实现正负极间的离子传导。锂电池四大主材分别为：正极材料、负极材料、隔膜、电解液(含六氟磷酸锂)。‌‌

　　Lithium hexafluorophosphate is neither a positive nor negative electrode material, but a core component of the electrolyte solute in lithium-ion batteries. It is a key raw material for the electrolyte (inorganic lithium salt) with the chemical formula LiPF ₆, which dissociates in organic solvents to provide lithium ions and achieve ion conduction between the positive and negative electrodes. The four main materials of lithium batteries are: positive electrode material, negative electrode material, separator, and electrolyte (including lithium hexafluorophosphate). ‌‌

　　极 致耐磨抗冲蚀‌：碳化钨显微硬度达 HV 1500–1800(HRA 90+)，仅次于金刚石，对磨粒磨损、气固两相流冲击的耐受性比不锈钢/司太立合金高 3–100 倍，有效防止转子/阀芯表面形成沟槽、凹坑。

　　防金属接触：禁铜、锌等金属接触。

　　维持密封精度‌：减少因磨损导致的转子与阀体间隙扩大，避免物料泄漏、杂质侵入或卡阻故障，延长密封件寿命，保障连续生产稳定性。

　　Ultimate wear resistance and erosion resistance: The microhardness of tungsten carbide reaches HV 1500-1800 (HRA 90+), second only to diamond. Its resistance to abrasive wear and gas-solid two-phase flow impact is 3-100 times higher than that of stainless steel/Stellite alloy, effectively preventing the formation of grooves and pits on the surface of the rotor/valve core.

　　Anti metal contact: Copper, zinc and other metals are prohibited from coming into contact.

　　Maintain sealing accuracy: reduce the expansion of the gap between the rotor and the valve body caused by wear, avoid material leakage, impurity intrusion, or blockage faults, extend the life of the seal, and ensure continuous production stability.

　　电动破碎阀主要由‌驱动系统、传动系统、破碎执行机构、阀体与密封组件‌四大部分构成。破碎过程‌：物料落入阀体后，大块料被旋转齿、叶片或双轴反向剪切机构(可以各种破碎齿)通过‌挤压、剪切、撞击‌作用打散，粒度控制在可输送范围(通常≤10mm，定制版5mm~6mm)。

　　The electric crushing valve mainly consists of four parts: the drive system, transmission system, crushing actuator, valve body, and sealing components. Crushing process: After the material falls into the valve body, large pieces of material are dispersed by rotating teeth, blades, or biaxial reverse shearing mechanisms (which can be various crushing teeth) through squeezing, shearing, and impact, with particle size controlled within the transportable range (usually ≤ 10mm, customized version 5mm~6mm).

　　常州同得利机械厂拥有多年的研发生产/定制卸料阀旋转阀的经验，秉承质量第 一、用户至 上的原则。我们的旋转阀能够处理锂电池、钢厂、电厂、水泥、矿山、环保、塑料、化工、食品和医药等行业的各种颗粒、片状、块状物料、粘料、粉料、超微粉体等。

　　Changzhou Tongdeli Machinery Factory has many years of experience in research and development, production/customization of discharge valve rotary valves, adhering to the principle of quality first and customer first. Our rotary valves are capable of handling various types of particles, flakes, blocks, adhesives, powders, ultrafine powders, etc. in industries such as lithium batteries, steel mills, power plants, cement, mining, environmental protection, plastics, chemical, food, and pharmaceuticals.

　　正极块料破碎阀 负极块料破碎器 锂电行业打散卸料器 锂电极片涂覆及隔膜涂层材料打散破碎阀  氮化硼打散阀 石墨电动破碎阀  镍包石墨破碎阀 电解锰片打散卸料阀 锂电池碳酸锂电动破碎阀
