尼龙旋转卸料阀由本公司自主研制，适用于不可接触金属物料的卸料。箱体、叶轮以及端盖，都采用整块尼龙铣削加工，结构牢靠，运行无噪音，相较于陶瓷阀，可以节省成本，是锂电行业新宠。　　采用加厚叶轮设计，与壳体配合间隙小，结构精密，使用过程中不易漏风不易漏料，防堵耐用。　　密封优越，用感无忧：结构稳定，密封性能良好。可用于粉料、小颗粒物料，在正负极压差吸送过程中将物料分离排出。　　The nylon rotary discharge valve is independently developed by our company and is suitable for unloading non-contact metal materials. The casing, impeller, and end cover are all processed using a single piece of nylon milling, with a reliable structure and noiseless operation. Compared to ceramic valves, they can save costs and are a new favorite in the lithium battery industry.　　Adopting a thickened impeller design, the clearance between the impeller and the shell is small, the structure is precise, and it is not easy to leak air or materials during use, and it is durable and anti clogging.　　Superior sealing and worry free use: stable structure and good sealing performance. Can be used for powder and small particle materials, to separate and discharge materials during the positive and negative pressure difference suction process.

　　卸料阀可分为：普通型，耐压型，外装耐温耐压型，快速清洗型，定量型。　　快速清洗型：快速清洗旋转阀制作精致、成功使用德、日技术制造之精华。产品拆装灵活、易于清洗。主要用于化工、制药、食品等行业高卫生标准的物料卸料及经常更换物料的场所工作。　　可拆卸叶轮：便于快速拆卸清洗旋转阀的物料接触面。　　驱动方式：链驱动/马达直连驱动。　　动力配置：摆线针轮减速机，Y系列电机(可按客户指定动力配置)。　　材质：改性尼龙系列。　　尼龙卸料阀适用于锂电正极材料输送，高镍三元材料，磷酸铁锂。阀体、端盖外表面采用304.物料接触8-10mm氧化铝陶瓷工艺等。都可以满足工况耐磨，耐温尤为突出。　　The discharge valve can be divided into: ordinary type, pressure resistant type, external temperature and pressure resistant type, quick cleaning type, and quantitative type.　　Rapid cleaning type: the rapid cleaning rotary valve is exquisitely made, and successfully uses the essence of German and Japanese technology. The product is flexible in disassembly and easy to clean. Mainly used for unloading materials with high hygiene standards in industries such as chemical, pharmaceutical, and food, as well as working in places where materials are frequently replaced.　　Detachable impeller: facilitates quick disassembly and cleaning of the material contact surface of the rotary valve.　　Drive mode: chain drive/motor direct connection drive.　　Power configuration: cycloidal pinwheel reducer, Y-series motor (can be configured according to customer specifications).　　Material: Modified nylon series.　　Nylon discharge valve is suitable for transporting lithium battery positive electrode materials, high nickel ternary materials, and lithium iron phosphate. The outer surface of the valve body and end cover adopts 304 material contact 8-10mm alumina ceramic technology, etc. Both can meet the wear resistance requirements of working conditions, with outstanding temperature resistance.

适用于常规物料的正压负压输送卸料，加工精度高，漏气系数小，下料稳定。

根据使用方的要求，依据物料属性、使用工况，专注定制关风机卸料阀。

根据使用方的要求，依据物料属性、使用工况，专注定制关风机卸料阀。

我公司研制的静电喷涂专用卸料阀，解决因关风机的问题导致除尘器的运行不畅，维护简单，使用寿命增加，使用成本降低。

　　U型螺旋输送机(也称为U型绞龙输送机或U型螺杆上料机等)槽体两侧壁垂直，底部呈半圆型，内径通常比螺旋叶片直径大3~10mm，以减少摩擦并防止卡料 。驱动带动螺旋轴旋转，叶片推动物料沿U型槽轴向移动;物料自重与槽壁摩擦力阻止其随叶片圆周转动，仅做轴向前进，实现水平或小角度倾斜输送。　　The two side walls of the U-shaped screw conveyor (also known as U-shaped screw conveyor or U-shaped screw feeder, etc.) are vertical, and the bottom is semi-circular. The inner diameter is usually 3-10mm larger than the diameter of the screw blades to reduce friction and prevent material jamming. Drive the spiral shaft to rotate, and the blades push the material to move axially along the U-shaped groove; The self weight of the material and the frictional force of the groove wall prevent it from rotating along the circumference of the blade, and only move forward axially, achieving horizontal or small angle inclined conveying.　　同得利U型螺旋输送机：　　结构组成：主轴、螺旋叶片、料槽、机盖、驱动装置等。　　特点：物料定位输送;透明视窗查看物料流动。　　行业应用：锂电正负极、化工、制药、食品、塑料、水泥、冶金、钢厂、电厂、环保、矿山、等。　　规格参考‌：螺旋直径有LUS80、LUS100、LUS150、LUS200、LUS250、LUS300、LUS400、LUS500、LUS600、LUS800、LUS1000、LUS1200等规格，或者非标定制;输送量1m³/h~460m³/h。　　材质：材质：陶瓷、碳化钨、尼龙、四氟、特氟龙、钛合金、铝合金、不锈钢、碳钢等。　　304(06Cr19Ni10)、316(06Cr17Ni12Mo2)、321(06Cr18Ni11Ti)、310S(06Cr25Ni20)、双相不锈钢2205(022Cr23Ni5Mo3N)、2507(022Cr25Ni7Mo4N) 　　Tongdeli U-shaped screw conveyor:　　Structural composition: spindle, spiral blades, material trough, machine cover, driving device, etc.　　Features: Material positioning and conveying; View material flow through a transparent window.　　Industry applications: lithium battery positive and negative electrodes, chemical, pharmaceutical, food, plastic, cement, metallurgy, steel mills, power plants, environmental protection, mining, etc.　　Specification reference: Spiral diameter available LUS80、LUS100、LUS150、LUS200、LUS250、LUS300、LUS400、LUS500、LUS600、LUS800、LUS1000、LUS1200 Equal specifications or non-standard customization; The conveying capacity ranges from 1m ³/h to 460m ³/h.　　Materials: ceramics, tungsten carbide, nylon, PTFE, PTFE, titanium alloy, aluminum alloy, stainless steel, carbon steel, etc.　　304 (06Cr19Ni10), 316 (06Cr17Ni12Mo2), 321 (06Cr18Ni11Ti), 310S (06Cr25Ni20), duplex stainless steel 2205 (022Cr23Ni5Mo3N), 2507 (022Cr25Ni7Mo4N)　　同得利U型螺旋输送机特点：　　1、优异的密闭性：螺旋输送机的结构特点使得其具有优异的密封性能和防尘效果。U型螺旋输送机配备了填料密封或机械密封装置，及气密封装置，均可按需采用多道密封，性能值拉满，进一步防止物料泄漏与粉尘外溢。　　2、物料适应性较强：能够处理各种散装物料，如颗粒状、粉状和块状的物品，适用于多种行业领域的应用场景。　　3、承载能力强，运行安全可靠：U型螺旋输送机采用高强度螺旋轴和耐磨叶片，整机运行平稳，可稳定承载各类粉状、颗粒物料的长周期输送任务。设计符合JB/T7679-2008《螺旋输送机》专 业标准，从设计源头保证了设备的可靠性。物料在叶片推动下形成定向输送，同时受槽体壁面约束，输送过程稳定可控。　　4、布置灵活，可多点装卸料：U型螺旋输送机支持输送线路上任意一点装载或卸载，可实现多点进料、多点卸料。输送方向可逆向，也可同时向相反两方向输送，出料口位置灵活可调。　　5、能耗较低：同得利由于采用了先进的传动技术和合理的结构设计，U型螺旋输送机在运行过程中能源消耗较小;此外，它还具备了操作简单、维护方便等特点。　　Characteristics of Tongdeli U-shaped screw conveyor:　　1. The structural characteristics of the excellent airtight screw conveyor make it have excellent sealing performance and dust-proof effect. The U-shaped screw conveyor is equipped with packing seal or mechanical seal device, as well as gas seal device, which can adopt multiple seals as needed, with full performance value to further prevent material leakage and dust overflow.　　2. Strong material adaptability: able to handle various bulk materials, such as granular, powdery, and block shaped items, suitable for application scenarios in various industries.　　3. Strong carrying capacity and safe and reliable operation: The U-shaped screw conveyor adopts high-strength screw shafts and wear-resistant blades, ensuring smooth operation and stable carrying of various powder and granular materials for long-term conveying tasks. The design complies with the professional standard JB/T7679-2008 "Spiral Conveyor", ensuring the reliability of the equipment from the design source. The material is transported in a directional manner under the push of the blades, while being constrained by the wall of the tank, ensuring a stable and controllable conveying process.　　4. Flexible arrangement and multi-point loading and unloading: The U-shaped screw conveyor supports loading or unloading at any point on the conveyor line, enabling multi-point feeding and unloading. The conveying direction can be reversed or conveyed in opposite directions simultaneously, and the position of the discharge port is flexible and adjustable.　　5. Low energy consumption: Due to the use of advanced transmission technology and reasonable structural design, the U-shaped screw conveyor consumes less energy during operation; In addition, it also has the characteristics of simple operation and easy maintenance.　　部分客户需求：　　锂电负极排料旋转阀+U型螺旋上料机：3t/h，尺寸：DN250.主体材质：SUS304;叶片数量：16片;旋转叶片与内壁间隙要求：0.15-0.2mm;工频电机：1.1KW;33转/分钟，额定电流：2.6A;电机：安徽皖南，减速机：国贸减速机，新国标二级能效IE4.IP55;采用多腔设计;配有填料+油封;密封锁气;减速机齿轮箱采用硬齿面;轴端密封须可靠，不出现漏粉情况，轴端密封采用石墨盘根密封。　　物料:磷酸铁锂中间体，粒径，1mm~3mm，D50:1mm，堆积密度:1100kg/m;螺旋上料机尺寸300.长度4米;物料接触部分材质:SS310S，内腔及叶片抛光，处理能力:2t/h，设计温度>300°C,石墨盘根+迷宫密封，防爆等级:安全区，电机，变频。　　破碎卸料阀+螺旋输送机，破碎阀DN500. PN6.介质：锂辉石酸化熟料，破碎前≤30mm,破碎到≤8mm;物料堆密度850g/m³;介质流量20t/h;工作温度300℃。水平式螺旋输送机，长度6米，材质不锈钢。　　破碎阀+U型螺旋给料机，食品行业用，用螺旋给料机输送到破碎阀，然后调入混合机;物料是糖粉，在口袋中结块了，螺旋输送机大概长度6米，破碎后再混合，破碎得越细越均匀越好，进料口DN200的法兰，304材质，食品级抛光。　　食品级螺旋绞龙输送机(快拆易清洗)，DN250.绞龙输送机长度3米。物料接触部分材质为食用级SUS304.变频电机，粉尘防爆，物料名称：麦芽糖醇，颗粒物，40℃~50℃，物物料粒度10目，堆积密度0.82g/cm³。     《扫二维码-添加 陈经理 微信-咨询U型螺旋上料机》　　Partial customer requirements:　　Lithium battery negative electrode discharge rotary valve+U-shaped spiral feeder: 3t/h, size: DN250. main material: SUS304; Number of leaves: 16 pieces; Requirements for clearance between rotating blades and inner wall: 0.15-0.2mm; Power frequency motor: 1.1KW; 33 revolutions per minute, rated current: 2.6A; Motor: Anhui Wannan, reducer: Guomao reducer, new national standard second level energy efficiency IE4. IP55; Adopting a multi cavity design; Equipped with packing and oil seal; Sealing and gas locking; The gearbox of the reducer adopts a hard tooth surface; The shaft end seal must be reliable and free of powder leakage. The shaft end seal adopts graphite packing seal.　　Material: Lithium iron phosphate intermediate, particle size, 1mm~3mm, D50: 1mm, bulk density: 1100kg/m; Spiral feeder size 300. length 4 meters; Material contact part material: SS310S, inner cavity and blade polished, processing capacity: 2t/h, design temperature>300 ° C, graphite packing+labyrinth seal, explosion-proof level: safe zone, motor, frequency converter.　　Crushing discharge valve+screw conveyor, crushing valve DN500. PN6. medium: spodumene acid clinker, ≤ 30mm before crushing, ≤ 8mm after crushing; material bulk density 850g/m ³; Medium flow rate of 20t/h; The working temperature is 300 ℃. Horizontal screw conveyor, 6 meters in length, made of stainless steel material.　　Crushing valve+U-shaped screw feeder, used in the food industry, is conveyed to the crushing valve by the screw feeder, and then transferred to the mixer; The material is powdered sugar, which has clumped in the pocket. The screw conveyor is about 6 meters long and is crushed before mixing. The finer and more uniform the crushing, the better. The inlet has a DN200 flange, made of 304 material, and polished to food grade.　　Food grade spiral screw conveyor (quick disassembly and easy cleaning), DN250. The length of the screw conveyor is 3 meters. The material in contact with the material is food grade SUS304. variable frequency motor, dust explosion-proof, material name: maltitol, particulate matter, 40 ℃~50 ℃, material particle size 10 mesh, bulk density 0.82g/cm ³.

　　锂电、食品、制药、化工行业打散破碎大块料物料(介质)的电动破碎阀，常用‌不锈钢 304/316L‌材质，以满足高卫生要求和耐腐蚀工况。不锈钢破碎阀集结星型卸料阀定量卸料及密封锁气功能，还有蕞大特点为打散破碎块料功能，常规破碎至6mm~10mm，<6mm按需定制生产。　　The electric crushing valve for breaking and crushing large block materials (media) in the lithium battery, food, pharmaceutical, and chemical industries is commonly made of stainless steel 304/316L material to meet high hygiene requirements and corrosion-resistant working conditions. The stainless steel crushing valve is equipped with a star shaped discharge valve for quantitative discharge and sealing and air locking functions. Its biggest feature is the ability to break up and crush block materials. It is commonly used for crushing to 6mm~10mm, and can be customized for production when it is less than 6mm.　　‌‌‌　　锂电池经绝缘仓进活动阀真空给料，破室进出料闭氧抽空充惰性气体(常规用氮气和二氧化碳);惰性气体作用为提高电解液闪点和挥发点，同时抑制锂离子从负极到正极几率，防止放电发热和爆燃;锂电破碎时转子刀与底刀相切破，并起摩擦打散防止金属壳体包裹正负极片，碎后物料通过真空排料进行外排。　　Lithium batteries are vacuum fed into the movable valve through the insulation compartment, and the inlet and outlet of the broken chamber are closed and oxygen is evacuated to fill with inert gas (usually nitrogen and carbon dioxide); The role of inert gas is to increase the flash point and volatilization point of the electrolyte, while suppressing the probability of lithium ions from the negative electrode to the positive electrode, preventing discharge heating and explosion; When the lithium battery is broken, the rotor blade and the bottom blade are tangent and broken, and friction is generated to break and prevent the metal shell from wrapping the positive and negative electrode pieces. After the breakage, the material is discharged through vacuum discharge.　　物料：氧化铝粉末从烘干设备出来可能会成团，需打散，块料硬度一般，蕞大块料大致8cm，一小时输送量5t，气密封，尺寸DN300.材质316L。导热粉体材料(球形氧化铝、类球形氧化铝、氮化铝、氮化硼)、电磁屏蔽粉体材料(镍包石墨)，以及锂电极片涂覆及隔膜涂层材料等。　　物料：可可饼，榨过油的，卸料量200kg/h，物料状况2*2cm，破碎后小于10mm，材质不锈钢304.破碎尺寸300*300.　　生物医药管道破碎机设备(BPSF-DN200)，物料名称：名称： 度洛西汀单甲基;物料体积：1200L/650kg，进料参数要求：200kg/h，出料参数要求： 粒径<8mm，材质316L。电机采用气体粉尘双防爆，能效等级2级，ExdIIBT4Gb/ExtDA211P65T130°。　　Materials: Aluminum oxide powder may form clusters when coming out of the drying equipment and needs to be dispersed. The hardness of the blocks is generally average, with a maximum block size of about 8cm and a conveying capacity of 5t per hour. It is airtight, with a size of DN300 and made of 316L material. Thermal conductive powder materials (spherical aluminum oxide, quasi spherical aluminum oxide, aluminum nitride, boron nitride), electromagnetic shielding powder materials (nickel coated graphite), as well as lithium electrode sheet coating and diaphragm coating materials, etc.　　Material: Cocoa cake, pressed with oil, discharge capacity 200kg/h, material condition 2 * 2cm, crushed to less than 10mm, material 304 stainless steel, crushing size 300 * 300.　　Biomedical Pipeline Crusher Equipment (BPSF-DN200), Material Name: Duloxetine Monomethyl; Material volume: 1200L/650kg, feed parameter requirement: 200kg/h, discharge parameter requirement: particle size<8mm, material 316L. The motor adopts gas dust dual explosion-proof, energy efficiency level 2. ExdIIBT4Gb/ExtDA211P65T130 °.　　不锈钢破碎阀原理：　　电机驱动带放射状破碎爪的转子转动，把块料拨进阀体并压向栅格，靠挤压和剪切把块料打碎‌。‌‌　　经过打散后的物料从设备下方排出，再进入螺旋输送机、皮带输送机、称重设备、包装机或其他工艺设备。　　Principle of stainless steel crushing valve:　　The motor drives the rotor with radial crushing claws to rotate, pushing the block material into the valve body and pressing it against the grid. The block material is crushed by squeezing and shearing. ‌‌　　After being dispersed, the material is discharged from below the equipment and then enters the screw conveyor, belt conveyor, weighing equipment, packaging machine or other process equipment.　　其基本工作流程为：　　结块物料进入 → 旋转破碎 → 剪切打散 → 块料变小 → 均匀排出 → 下游输送　　不锈钢破碎阀结构：　　阀体、破碎刀齿、轴承组件、旋转轴、减速电机、密封结构及出料接口组成。　　可根据客户要求选择多种材质：不锈钢(SS304、SS304L、SS316、SS316L)　　破碎出料粒度：6mm~10mm，或1cm~3cm，或<6mm定制，均可按需定制。　　The basic workflow is as follows:　　Agglomerated materials enter → rotate and crush → shear and disperse → block material becomes smaller → evenly discharged → downstream transportation　　Stainless steel crushing valve structure:　　The valve body, crushing blade teeth, bearing components, rotating shaft, reduction motor, sealing structure, and discharge interface are composed of.　　Multiple materials can be selected according to customer requirements: stainless steel (SS304. SS304L, SS316. SS316L)　　Crushed material particle size: 6mm~10mm, or 1cm~3cm, or<6mm can be customized according to needs.　　常州同得利机械厂/江苏同得利科技专 业的团队，拥有二十余年经验，定制、设计、研发、生产经验丰富。为您提供专 业的设计、选材和指导，为不同使用工况量身打造一体化的输送设备。自动精加工中心，搭配进口自动设备，专有生产工装，提高生产效率和精度。　　Changzhou Tongdeli Machinery Factory/Jiangsu Tongdeli Technology has a professional team with over 20 years of experience in customization, design, research and development, and production. We provide professional design, material selection, and guidance to tailor integrated conveying equipment for different operating conditions. Automatic precision machining center, equipped with imported automatic equipment and proprietary production fixtures, improves production efficiency and accuracy.　　部分客户需求：　　物料：阳极碳块，原料小颗粒状，经过某工艺结块后需要破碎打散一下，下料口500*500.破碎到2~3cm左右即可，电机要求一级能效防爆的，减速机国茂，材质不锈钢316.　　小型低速双齿辊结块打散机，物料：化工结晶物料;物料特性：不易燃、无吸潮、干燥固态;脆性结晶，能敲击、强挤压破碎原生晶粒，只拆散堆积结块;进料粒度：蕞大进料边长 100~500mm;额定处理量：5.0 t/h，尺寸500*500.材质304不锈钢，防爆：隔爆 EXdⅡCT4.电机采用SEW/诺德/住友/国茂减速电机。　　Partial customer requirements:　　Material: Anode carbon block, small granular raw material, needs to be crushed and dispersed after a certain process of agglomeration. The feeding port is 500 * 500. and it can be crushed to about 2-3cm. The motor requires first level energy efficiency and explosion-proof. The reducer is made of Guomao stainless steel 316.　　Small low-speed double toothed roller clumping and breaking machine, material: chemical crystalline material; Material characteristics: non flammable, non hygroscopic, dry solid; Brittle crystallization, capable of knocking and forcefully crushing primary grains, only disassembling accumulated lumps; Feed particle size: maximum feed side length 100-500mm; rated processing capacity: 5.0 t/h, size 500 * 500. material 304 stainless steel, explosion-proof: explosion-proof EXd Ⅱ CT4. motor adopts SEW/Nord/Sumitomo/Guomao reduction motor.　　破碎卸料阀、料仓破块阀、破块阀、破团阀、打散机、块料破碎器、旋转破碎阀、管道不锈钢破碎阀、304不锈钢破碎阀、316不锈钢破碎阀、316L不锈钢破碎阀、破碎下料阀、食品破碎卸料阀、电动破碎阀_pdk300、不锈钢破碎卸料器、滑杆式破碎卸料器、破碎阀 PSB500H、304材质破碎阀、食品粉料块破碎打散阀　　Crushing and unloading valve, silo crushing valve, crushing valve, ball breaking valve, disperser, block crusher, rotary crushing valve, pipeline stainless steel crushing valve, 304 stainless steel crushing valve, 316 stainless steel crushing valve, 316L stainless steel crushing valve, crushing and unloading valve, food crushing and unloading valve, electric crushing valve _pdk300. stainless steel crushing and unloading device, sliding rod crushing and unloading device, crushing valve PSB 500H, 304 material crushing valve, food powder block crushing and dispersing valve
